Epoxy Fiberglass Resin Insulation Material Tube

Name: Epoxy Fiberglass Resin Insulation Material Tube
Brand: all-electronics-online.com
SKU: 786470805
Availability: InStock
Rating: 4.3 (102 reviews)

Price:	US $ 5.2-8.9KG
Min Order:	300KG
Pay Type:	L/C,T/T,D/P,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	MJ-3641-150
Size:	According to Customer Requirement
Density:	1.9g/cm3
Delievery Time:	Within 7-10 Working Days
Sample:	Free
Application:	Switch Baseplate
Type:	Insulation Sleeve
Chemistry:	Hybrid Insulation
Material:	Fiberglass
Thermal Rating:	B 130
Maximum Voltage:	>100KV
Color:	Green
Brand:	Mj

Product Description

3641- 150 Insulation Laminate Epoxy Rod /Pole

Appearance:
Surface smoothly without bubble and impurities

Feature:
Excellent mechanical & electric property
Good heat & moisture resistance
Easy for processing & machining
High mechanical strength

Application:
Used as insulating tube/pipe in high voltage arrester and high voltage switch

Packaging Detail: Epoxy slot wedge package: Each package is not more than 100KG. Respectively, paper and plastic film cover plate, a paper packaging box, steel strapping / or according to customers' requirements.

Delivery Detail: 7-10 working days

Technical Parameters
Parameter		Result
Density		1.8-2.0g/cm3
Water Absorption		<0.02%
Bending Strength		350 Mpa
Compression Strength		240 Mpa
Tensile Strength (axial)		400Mpa
Tensile Strength (circumference force)		600Mpa
Tensile elastic modulus(acial)		14000Mpa
Glass transition temperature		110-135ºC
Frequency stamping		50 KV
lightning impulse		110kv
Dielectric dissipation factor		0.003-0.015
Shearing Strength		150Mpa
Fiber content		70%-75%
Resin content		30%-25%
Insulation Resistance (axial)		3-6kv/mm
Insulation Resistance (radial)		10-12kv/mm

Our company is in Xi' An high tech Development Zone, mainly producing magnetic/electrical insulation laminates, slot wedges, thermal expansion materials, insulation varnish, impregnated cloth, insulation tube/sleeve/rod and etc. Our products are widely used in the fields of wind & thermal power, aviation, railway, military power transmission, motors and transformers and etc.

We have experts in R&D group which ensure the continuity and stability of the product quality and cost. The issued testing results apply to domestic and internaltional standards.

Our company covers 5000 square meters with 4 production departments: Magnetic board, Insulating materials, High voltage electrical appliance, CNC and slot wedge processing. WIth more than 50 sets of reactor, gluing machine, large-scale equipment, hot press, high vacuum impregnation and testing equipments, our annual production capacity can totally reach 800 tons.

We are founded in 2006. By 2007-2008, we passed 9001-2000 certification, Xi' An city Science and Technology Bureau identified us as "the city of Xi' An high-tech enterprises".

The spirit of our company is: "Good Reputation, Best Products, Wonderful Services
