Epoxy Insulation Fiberglassfabric Laminated Slot Wedge

Name: Epoxy Insulation Fiberglassfabric Laminated Slot Wedge
Brand: all-electronics-online.com
SKU: 785665175
Availability: InStock
Rating: 4.9 (84 reviews)

Price:	US $ 0.3-1/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	MJ-3240
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	980X1220mm
Shape:	According to Customer Requirement
Thickness:	0.5-50mm Available
Density:	1.9g/cm3
Formation Methods:	High Temperature and High Pressure
Tensile Strength:	300 MPa
Samples:	Free Samples Available
Appliction:	Electrical Insulation
Delivery Time:	7-10 Working Days
Customizable:	Yes
Application:	Generator
Chemistry:	Hybrid Insulation
Material:	Fiberglass
Thermal Rating:	B 130
Maximum Voltage:	20KV~100KV
Type:	Insulation Profile
Brand:	Mj

Product Description

Feature:
Excellent mechanical property
Good electric property
Good heat & moisture resistance
Easy for installing
Application:
Motors & generators
Traction motors
High-speed motors
Wind turbines Metro reactors

Basic information
Product name	3240 Electrical Insulation Stator Wedge
Item No.	With the same item numbers of the laminates which used for processing
Brand	MJ
Material	Epoxy resin and Alkali free fiberglass cloth
Grade	Grade B
Technical Performance
Density	≥2.0g/cm 3
Appearance	Natural color Yellow, surface smoothly without bubble and impurities, no flow marks, Cutting edge without fault and separation
Sheets Thickness	0.1-50mm
Size	Customized
Formation methods	High temperature and high pressure
Thermal stability in 24h	≥180°C
Water Absorption (D-24/23, 1.6mm	21.5 mg
Impact strength parallel to layer (Charpy method)	≥34.5 KJ/m 2
Tensile strength	≥300 Mpa
Flexural strength perpendicular to layer at room temperature at high temperature 180±2°C	≥345MPa ≥340MPa
Insulation Resistance after immersion in water (D-24/23)	5.1×10 8 W
Dielectric Strength perpendicular to laminations (in 90±2 °C transformer oil, 1 mm)	10.4 KV/mm
Voltage resistance parallel to layer (at 90±2°C oil for 1min)	≥30 kV
Breakdown Voltage parallel to laminations (in 90±2°C transformer oil)	≥36.1 kV
Permittivity (50Hz)	5
Permittivity (1MHz)	5.1
Dissipation Factor (50Hz)	0.032
Dissipation Factor (1MHz)	0.032
Reference Standard	GB/T1303.1-1998

Our company is in Xi' An high tech Development Zone, mainly producing magnetic/electrical insulation laminates, slot wedges, thermal expansion materials, insulation varnish, impregnated cloth, insulation tube/sleeve/rod and etc. Our products are widely used in the fields of wind & thermal power, aviation, railway, military power transmission, motors and transformers and etc.

We have experts in R&D group which ensure the continuity and stability of the product quality and cost. The issued testing results apply to domestic and internaltional standards.

Our company covers 5000 square meters with 4 production departments: Magnetic board, Insulating materials, High voltage electrical appliance, CNC and slot wedge processing. WIth more than 50 sets of reactor, gluing machine, large-scale equipment, hot press, high vacuum impregnation and testing equipments, our annual production capacity can totally reach 800 tons.

We are founded in 2006. By 2007-2008, we passed 9001-2000 certification, Xi' An city Science and Technology Bureau identified us as "the city of Xi' An high-tech enterprises".

The spirit of our company is: "Good Reputation, Best Products, Wonderful Services
