Evaporator Fan Motor, C Frame Motor Model Swiss

Name: Evaporator Fan Motor, C Frame Motor Model Swiss
Brand: all-electronics-online.com
SKU: 609817585
Availability: InStock
Rating: 4.5 (115 reviews)

Price:	US $ 2.00/Piece
Trade Terms:	FOB,others
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	1312#
Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe
Application:	Household Appliances
Operating Speed:	Constant Speed
Number Of Stator:	Single-Phase
Rotor Structure:	Squirrel-Cage
Casing Protection:	Closed Type
Starting Mode:	Direct on-line Starting
Species:	C Frame Motor
Certification:	Ce
Brand:	as Customer's Requests

Product Description

Evaporator Fan Motor, C Frame Motor, Model SWISS

Applications:
1) Range hoods
2) Batheroom exhaust fans
3) Kitchen ventilators
4) Reach in cooler and freezer evaporators
5) Walk in cooler and freezer evaporators
6) Exhaust fans
7) Ventilatoer fans
8) Electric unit heaters
9) Forced air heaters

Feature:
1) Input Voltage: 220v (we can make from 100-240V)
2) Rated Frequency: 50HZ (we can make 50/60Hz)
3) Input Power: 10W (we can make from 5W-16W)
4) Working Condition: Continuous
5) Number of Pole: 2 Pole 3000RPM
6) Insulation Class: B/F/H
7) Speed number: 1-5
8) Environment Temp: -20 -40 degree
9) Core lamination thickness: 11mm(we can make from 7 to 50mm)
10) Shaft diameter: φ 4 (we can make from φ 3 to φ 12)
11) Bearing: Ball bearing/sleeve bearing
12) Usage: Home appliances, such as microwave ovens, humidifiers, aquarium pumps, copy machines, vending machines, cooker hood, juicer, fan, blower, freezer, refrigerator, air-conditioner, heater, dishwasher, automatic hand dryer, hair dryer, exhauster, air purifier, etc.
13) Small, Light weight, Low loss, Long lifespan, Good self-healing, High efficiency, High reliability, Little vibration, Low noise
14) We can also supply more motors with different voltages and frequencies according to client's requirement
15) Guarantee: One year after shipment

Ningbo Hairong Import & Export Co., Ltd. Specializes in manufacturing and marketing electric motor, reducer, axial fan, fan motor, water pump, blower, capacitors, switch, thermostat, timer and refrigeration parts.

Our products are manufactured strictly according to the national standard and the IEC regulation, which have been given relative certificates.

Developing business based on the quality is the tenet we have always held. Besides the products listed in our catalogues, we also offer OEM services.

At present, our products sell well widely to Europe, America and South-East Asia. We sincerely wish to cooperate with clients and friends worldwide to build a brilliant future together!
