| Prod Model: |
CC1-50 |
| Frequency: |
50Hz/60Hz |
| Main Coil Voltage: |
24V,36V,42V,48V,110V,127V,220V,230V,415V,480V,600V |
| Mechanical Life: |
1 Million Times |
| Electrical Life: |
1000000 Times(AC3) |
| Certificate: |
ISO9001/Ce/CB/Semko/CCC |
| Export Market: |
World |
| Quality: |
AAA |
Product Description
Product Description
Free samples can be provided!!!
Specifications:
CC1-D=LC1-D,
CC1-F=LC1-F,
CC1-K=LC1-K
1,General
Appliacatuon:Remote making&breaking circuits;Protect Circuit from over-load when assembing with thermal over-load relay;frequent start-up and control of Ac contactor;
Electric Ratings:AC50/60Hz,690V,up to 95A;
Utilization catagory:AC-3,AC-4
Altitude:<2000m,
Ambient temperature:-5ºC~+40ºC;
Mounting Cat:III
Mounting conditions:inckination between the mounting plane and the vertical plane should not exceed up&down 5ºC.
Standard:IEC/EN 60947-4-1
| Control Coil Valtage (Ac Coil Operation) |
| Volts(VAC) | 24 | 36 | 42 | 48 | 110 | 127 | 220 | 230 | 240 | 380 | 415 | 440 | 480 | 500 | 600 |
| Code | 50Hz | B5 | C5 | D5 | E5 | F5 | G5 | M5 | P5 | U5 | Q5 | N5 | R5 | | S5 | Y5 |
| 60Hz | B6 | | D6 | E6 | F6 | G6 | M6 | | U6 | Q6 | | R6 | T6 | | |
| 50/60Hz | B7 | | D7 | E7 | F7 | | M7 | P7 | | Q7 | N7 | R7 | | | |
| Control Coil Valtage (Dc Coil Operation) | | | | | | | | | | | | | | | | |
| Volts(VAC) | 12 | 24 | 36 | 48 | 110 | 220 | | | | | | | | | | |
| Code | JD | BD | CD | ED | FD | MD | | | | | | | | | | |
2 Technical Date
| Model No. | CC1-09 | CC1-12 | CC1-18 | CC1-25 | CC1-32 | CC1-40 | CC1-50 | CC1-65 | CC1-80 | CC1-95 | | |
| Rated Conventional Heating Current | Ith(A) | 20 | 20 | 32 | 40 | 50 | 60 | 80 | 80 | 100 | 125 | | |
| Rated Voltage Ui(V) | Ui(V) | 690 | 690 | 690 | 690 | 690 | 690 | 690 | 690 | 690 | 690 | | |
| Rated Operation Current Ue=380/415V | AC-3 Le(A) | 9 | 12 | 18 | 25 | 32 | 40 | 50 | 65 | 80 | 95 | | |
| AC-4 Le(A) | 3.5 | 5 | 7.7 | 8.5 | 12 | 18.5 | 24 | 28 | 37 | 44 | | |
| | 220/240 kW | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 25 | | |
| Power Controlled 3Ph Cage Motor AC3 | 380/415 kW | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | | |
| 660/690 kW | 5.5 | 7.5 | 10 | 15 | 18.5 | 30 | 33 | 37 | 45 | 45 | | |
| Eletrical life(x10^3 operations) | AC-3 | 1000 | 1000 | 1000 | 1000 | 800 | 800 | 600 | 600 | 600 | 600 | | |
| AC-4 | 200 | 200 | 200 | 200 | 200 | 150 | 150 | 150 | 100 | 100 | | |
| Mechainical life(x10^3 operations) | | 10 | 10 | 10 | 10 | 8 | 8 | 8 | 8 | 6 | 6 | | |
| Matched Fuse | Size | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | RT16-00 | | |
| A | 20 | 20 | 32 | 40 | 50 | 63 | 80 | 80 | 100 | 125 | | |
| Main Circuit | | 3P or 4P |
Packaging & Shipping
Shipping:
1,Shipping can delivery by sea,air,or express according to customer requirement
Payment:
1. Small order under 3000USD T/T100% in advance
2. 30% deposit and 70% before shipping or after received copy of B/L
3. L/C also acceptable
Our Services
Warranty:
1.We provide 1.5 year warranty.
2. Compensation will be paid if product had badly quality problem.
Company Information
About US:
Changan Group Co.,Ltd was established at years of 1987,which is leading of industrial electric appliances,integrating the research&development,manufacture,trade,information service functions together. At present,group have passed ISO9001,ISO14001,OHASA18001 and acquired 3C certification for all products,all of our export product are strictly production according to ISO9001 and IEC standard,some product had got CE,CB,SMEKO,KEMA certification.The company has owned 10 son companies,50 sales branch,3000 employees ,areas of 0.4 million square meters,registered capital reached 26 million,yearly out put value reached 346 million.The company has the honor to be titled as "China star enterprise","China top 500 private enterprise","China top 500 in machinery industry","China top 10 of LV electric appliance"
Lab room of IEC standart testing of AC contactor MCB and MCCB thermal relay and Fuse
FAQ
Q 1. what's the payment term?
A. We accept TT,30% deposit and 70% balance agaisnt the copy of B/L.
Q 2. how's the delivery time ?
A. usually it will take about 25 days for production
Q 3. tell me the standard of package?
A. Normally are cartons, but also we can pack it according to your requirement.
Q4.Could you offer Form A or C/O ?
A. It's totally not a problem.
We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q5.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Established in 1987, CHANGAN GROUP Co., Ltd. Has been acknowledged as one of the most respected nation-wide manufacturers and exporters of low-voltage electrical apparatus in P. R. China.
Comprising more than 62 factories with over 2500 employees and the whole corporation occupies 82000m2 ground during past 27 years.
We manufacture and export varieties of low voltage electrical appliance including all kinds of CIRCUIT BREAKER, CONTACTOR, RELAY, SWITCH, SOLAR INVERTER etc.
All of our production procedures strictly follow ISO9001, ISO14001 and OHSAS18001, most of our products are certified such as SEMKO, TUV, CB and CE which can prove our guarantee quality and our products also have been chosen as "Chinese FAMOUS BRAND PRODUCT".
We not only make efforts in developing our own products with "CHANA"brand but also provide OEM services. Hope to establish good business relationships with your esteemed company in near future.
