F Screw CATV RG6 Twist on F Connetcor (RG6 Twist On F Connetcor)

F Screw CATV RG6 Twist on F Connetcor (RG6 Twist On F Connetcor)
Price: US $ 0.02-0.04/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 500/Piece
Pay Type: L/C,T/T,Paypal,Western Union
Prod Model: RG6 Twist On F Connetcor
Length: 18mm/20mm
Material: Brass/Zinc
Cable Od: 6.8mm
Bandwidth: 0~1000MHz
Brand: Daytai
Interface Type: F Connector
Type: Twist on Connector

Product Description

Specifications
CATV Connector, RG6 Twist-on connector, suitable for RG6 Coaxial cable. Cable OD: 6.8mm. Length: 18mm or 20mm.

Twist on F Connector
1. Bandwidth: 0~1000MHz
2. Type: F
3. Gender: Male
4. Bandwidth: 0~1000MHz
5. Material: Brass or Zinc
6. Plating: Nickle plating
7. Length: 18mm or 20mm
8. For RG59/RG6 Coaxial Cable

Connector Application:
1. Audio
2. Video
Frequency RangeDC~1000MHz
Working Voltage335V max
Withstand Voltage750V rms
Contact resistance
Center Contact≤ 10 mΩ
Outer Contact≤ 5 mΩ
Insulation resistance≥ 1000 MΩ
Durability(mating)≥500(cycles)
Temp.range-50~+60°C
