F7 Residual Current Circuit Breaker

Name: F7 Residual Current Circuit Breaker
Brand: all-electronics-online.com
SKU: 161568
Availability: InStock
Rating: 4.6 (37 reviews)

Price:	US $ 3.7-4.6/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	F7
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Ampere:	6 to 63A
Rated Voltage:	230V
Residual Current:	30mA 100mA 300mA
Tripping Type:	Electronic or Magnetic
Current Type:	AC
Mechanical Life:	10000
Place Of Origin:	Zhejiang, China (Mainl)
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	MCB
Poles Number:	3
Certification:	CCC

Product Description

F7 rcd is in conform with the standards of iec1008, GB16916, the rcd can cut off the fault circuit immediately on the shock hazard or earth leakage of trunk, thus it is suitable to avoid the shock and fire caused by earth leakage.

The rcd is mainly suitable for use in variety of plants and enterprises, construction, commerce, guesthouses and families, it can be used in circuit single phase 230v, three phase 400v 50 to 60Hz. Rcd is not suitable for use DC pulse system.

Technical data
Standard: Iec1008
Rated voltage (un): 2 pole: 230v AC
4 pole: 400v AC
Rated current (in): 25, 40, 63a
Rated residual operating current (in): 30, 100, 300, 500ma
Residual current off-time: ≤0.1s
Minimum value of rated making and breaking capacity (im): 63a
Rated conditional short-circuit current (inc):
In=25, 40a inc=1500a
In=63a inc=3000a

Endurance: Installation
On load: 2000cycles on symmetrical din rail
Off load: 2000cycles panel mounting

Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.

From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:

1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.

2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.

3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.

4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on

5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on

Internationalization standard quality guarantee system:

The product quality of Tengen Group has been strictly controlled in each working procedure,

Many kinds of internationalization standard quality guaranteed system can be highly effective

Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently

Make sure of our product quality.

"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American

FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management

System authentication, CCC authentication, European Union CE safe Authentication, American UL

Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first

Side laboratory -- low voltage electric appliance test center which is the first connected with

International in China.

We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
