Factory Price 14.8V Li-ion LED Lighting Rechargeable Battery Pack
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
100/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
LP0148-0120-LP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Battery Size: |
H19*W56mm*L67mm |
| Packae: |
Antistatic Bag /White Box and Standard Export Cart |
| Delivery Date: |
15days |
| Warranty: |
One Year |
| Type: |
Lithium-Ion Battery Pack |
| Connection Mode: |
Series and Parallel |
| Standard Voltage: |
14.8V |
Product Description
Specifications
Factory price 14.8V li-ion rechargeable battery pack for LED lighting
capacity: 12000mAh
14.8V 4s4p 12000mAh li-ion battery pack
Features and Specifications:
- High quality 14.8 V Li-Ion rechargeable battery pack
- Made of 16 pcs 3000mAh cylindrical 18650 cells with PCB and poly switch for full protection
- Light weight and higher energy density than any rechargeable battery
- No memory effect and rechargeable
- Longer storage life than NiMH battery
- You can build 14.8V/4.8Ah Li-Ion battery pack by connecting two PCB ready battery modules in parallel
- Built-in IC chip will prevent battery pack from over charge and over discharge and prolongs battery life
- Ideal for replacing batteries for 12V HID (10 to 13W) and Diving Lights for long running time
- Perfect for building 14.8V battery pack for bike lighting, RC toy, robots, laptop and DVD external battery.
If you have any other needs of our battery pack, please no hesitate to let me know the
Messages below
1. What's the voltage and capacity you want?
Product Description
2. How about the operating current and peaking current of your machine?
3. The battery will be used for what?
4. How about your quantity?
Attention: If I am not online, please kindly leave a message. I am here waiting for you. Thanks!
| Item | Specification | Remark |
| Nominal capacity | 10000mAh | 0.2C discharge Cell: 9059156 |
| Nominal voltage | 14.8V | 3.7V / 1Cell |
| Charging voltage | 16.8V±0.1V | 4.2V / 1Cell |
| Charging method | CC/CV | (Constant-current and -Voltage with Limited current |
| Standard charging time | 2000mA/7.5hour\5000mA/3hour | Battery capacity÷charging current×1.5 |
| Maximum charging current | 5000mA(0.5C) | 0~+45° |
| Continuous discharge current | 10000mA(1C) | -20~+60° |
| Maximum discharge current | 20000mA(2C) | -20~+60° |
| Discharge cutoff voltage | 11V | 2.75V / 1Cell |
| Short circuit protection | Exterior short circuit | Automatic recovery |
| Internal resistance | ≤100mΩ | AC Impedance 1kHz |
| Cycle life | ≥500 |
|
| Operating temperature | Standard Charge | 0~+45° |
|
| Standard Discharge | -20~+60° |
|
| Temperature range for storage | -20 ~ 20° | less than 1 year | Percentage of recoverable capacity 80 |
| -20 ~ 45° | less than 3 months |
| -20 ~ 60° | less than 1 month |
| UL/UN approved | UL | UN | UL:single cell\UN:pack |
| Weight | 750 gram |
|
| Outline dimension | 162×63×44 | Length x wide x height |
| Pre-wired | 150mm length 18 AWG wires without connector | Red = Positive,Black = Negative |
| Protection Circuit Module |
| Balance voltage | 4.20V±0.025V | single cell |
| Balance current | 42±3mA | single cell |
| Over-charge detection voltage | 4.35V±0.025V | single cell |
| Over-charge release voltage | 4.15V±0.05V | single cell |
| Over-charge detection delay time | 0.5S_1.5S | single cell |
| Over-discharge detection voltage | 2.40V±0.08V | single cell |
| Over-discharge release Voltage | 3.0±0.10V | single cell |
| Over-discharge detection delay time | 50_150ms | single cell |
| Over-current detection | 15±2A | can adjust |
| Over-current delay time | 5ms_15ms |
|
| Battery pack | PCM:PCM-B04S10-187 |
|
|
