| Prod Model: |
DXD-600W-10A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Power: |
600W |
| Peak Power: |
1200W |
| Input Voltage: |
DC12V/ 24V |
| Output Voltage: |
AC110V/ 220V/ 230V |
| Output Frequency: |
50/60Hz |
| Output Waveform: |
Modified Sine Wave |
| AMP Of Battery Charger: |
10A |
| Max Outer Temperature: |
<65c |
| UPS Function: |
Yes |
| Overvoltage / Lowvoltage Protection: |
Yes |
| Type: |
DC/AC Inverters |
| Phase: |
Single |
| Power Source: |
Electric Power |
| Output Power: |
501 - 1000W |
| Brand: |
Doxin |
Product Description
Factory price for 1200W peak modified sine wave with charger-10A
Product Description
Feature:
1) It is featured as high reliability, and low failure rate, with the advanced double CPU SCM intelligent controlling technology.
2) Pure sine wave output, strong ability of driving load, wide range of application
3) Perfect protection functions (Overload protection, inside overheat protection, output short circuit protection, input low-voltage protection, input overvoltage protection), enhanced the reliability of the product.
4) Small and light: With the technology of CPU centralized control and SMD inside, the product is very small and light.
5) Intelligent control of cooling fan: Using CPU to control the working status of the cooling fans extends the service life of the cooling fans, saves the power and improves the working efficiency.
6) Low noise but high efficiency while working.
Application:
1) In-car or on-boat devices series: Military vehicle, police cars, medical ambulance, ships, traffic lights, and etc.
2) Industry equipments series: Solar energy, wind power, gas discharge lamp and etc.
3) Office area: Computer, printer, copier, scanner, digital camera and etc.
4) Kitchen utensils series: Micro-wave oven, induction cooker, refrigerator, and etc.
5) House appliance devices: Electric fans, vacuum cleaner, AC, lighting lamps, and etc.
6) Power tool series: Electric saw, drilling machine, punching machines, air compressor etc.
Features:
1. Output waveform: Modified sine wave
2. High efficiency: 85%
3.12V DC input
4.220V-240V AC output
5. Output frequency: 50Hz
6. Rated power: 600W
7. Peak power: 1200W
8. High-velocity cooling fan
9. Overload protect, over voltage protect
10. Low voltage cut-out, low voltage alarm
Warranty: One year
If you can cooperate with us, we will be honored and you will benefit from:
1. The good construction warranty-1 years
2. Your client satisfied on the right schedule and quality
3. Your can get good reputation from your market and obtain more orders
4. Our professional service before and after sale
5. The free inverter samples after your first 3 orders
6. The reasonable price
7. Any questions from you are welcome and will be replied in 24 hours
Customer Service
If you have any question, you can contact with us on line or contact us through email to me, we will assist you in any way possible and aim to answer all emails within
12-24 hours.
· OEM Services
· 1. Logo Please offer us your own high resolution logo in JPG format, there should be two colors at most in the logo and there should be no gradient effect in the logo.
· 2. Label Please offer us your own model numbers.
· 3. Manual Please offer us the finished manual file that can be printed directly.
· 4. Packing Box We will offer you the dimension and the design file. Please design your own style based
On this file then send it back to us. We will print some samples for your checking
· Lead Time
· 1. Sample orders will be delivered from our factory within 7 working days.
· 2. General orders will be delivered from our factory within 7-15 working days.
· 3. Big orders will be delivered from our factory within 25 working days at most.
· Shipment
· 1. By EMS, DHL, FedEx, TNT, UPS or other express.
· 2. By our forwarding agent(by air or by sea).
· 3. By your own forwarding agent.
· 4. By domestic forwarding agents to any city in China.
|
|
DXP600W |
|
Input |
Voltage |
DC12V |
|
|
Voltage Range |
11-15V |
|
No load Current Draw |
<3A |
|
Efficiency |
Average 85% max 90% |
|
Connector |
Cables with connector |
|
Output |
AC Voltage |
AC110/220V |
|
Continuous Power |
500W |
|
Surge Power |
1200W |
|
Waveform |
Modified sine wave |
|
Frequency |
50Hz or 60Hz |
|
Protection |
Low Voltage Alarm |
YES 10.2-10.8V |
|
Low Voltage Protection |
YES 9.2-9.8V |
|
Over Load Protection |
YES (120%-130% ) |
|
Over Voltage Protection |
YES 15-15V |
|
Thermal Protection |
YES, ( shutdown ) |
|
Short circuit protection |
YES, ( shutdown ) |
|
Environment |
Working Temperature |
-5° C ~ +40° C |
|
Working Humidity |
10%-90% |
|
Storage Temperature |
-20° C ~ +50° C |
|
Storage Humidity |
5%-95% RH |
|
Package |
Dimension( L*W*H ) |
61*37.5*26.0(cm) |
|
Net Weight |
20.8Kg |
|
Gross Weight |
22.0Kg |
|
Qty/CTN |
1pc/CTN |
|
|
Cooling |
Cooling Fan |
|
Total Harmonic Distortion |
THD<3% |
|
Certification |
CE |
