FC-FC Mm Duplex Fiber Optic Patch Cord

Name: FC-FC Mm Duplex Fiber Optic Patch Cord
Brand: all-electronics-online.com
SKU: 726555605
Availability: InStock
Rating: 4.4 (52 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FC-FC MD
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Any Length Is Ok:	Boots Colors Can Be Customized
Cable Diameter Can Be Customized:	Cable Jacket PVC or Lszh Can Be Chose
Application:	Communication
Type:	Multi-mode Fiber
Connection Structure:	FC-FC
Certification:	ISO9001

Product Description

These FC-FC cable assemblies are constructed from high quality FC connectors and 9/125 (OS1) grade Cable

Fiber patch cord Complies with IEC, Telcordia GR-326-CORE standard
Loss :Low insertion loss and high return loss
Polishing:PC/UPC/APC polishing
Diameter:0.9, 2.0, and 3.0mm
Mode:Single or multi mode is available
Core:4 fiber, 6 fiber, 8 fiber 12 fiber or 24 fiber is available
Jacket:PVC or LSZH cable is available

Excellent changeability and repeatability

Tensile strength:10N
Operating temperature range:-40 to 80°C
Storage temperature range:-40 to 80°C
Color of cable:Yellow (SM), Orange (MM), and Aqua (OM3)
FC Connector

Spec.	fiber optic patch cord
Insertion loss	Less than 0.3 dB
Return loss	UPC more than 55 dB,APC more than 60dB
Repeatability	Less than 0.2 dB
Changeability	Less than 0.1 dB
Operating temperature range	-40 to 80°C
Storage temperature range	-40 to 80°C
Tensile strength	100N
Min. bending radius	35mm
Length	Customed
