| Prod Model: |
FC |
| Sleeve: |
Zr |
| Flange: |
Flange |
| Color: |
Metal |
| Mode: |
Single-Mode, Multi-Mode |
| Material: |
Metal |
| Structure: |
FC |
| Number Of Cores: |
Single-Core |
| Transmission Medium: |
Singlemode, Multimode |
| Ferrule Endface: |
Upc or APC |
| Shape: |
Round |
| Brand: |
Koc |
Product Description
With 15 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website www.koc.com.cn.
In case of need, please do not hesitate in contacting us.
Product Description
BRIEF INTRODUCTION
All of the adapters like SC,LC,FC,ST,MU,D4,DIN are use ceramic sleeve to connect connectors although they are different size and appearance. Each species has a lot of types and colors can be chose. Single mode and multi-mode are different performance and price. These adapters can locking the connectors and get low insertion loss to transmission optical signal, which have been widely applied to the CATV system, communications system, FTTx system, ODF, Local Area Networks, Wide Area Networks, Metro,Test equipment, Active device termination and so on. The ARK has nearly 10 years of experience in producing adapters and all of them are meet the Telcordia and IEC-61754 stander, the material compliance RoHS require.
APPLICATIONS
CATV
Metro
Telecommunication networks
Local Area Networks (LANs)
Test equipment
Data processing networks
FEATURES
High precision alignment
Nickel plated brass body
Compact design
Low insertion loss and back reflection loss
Choice of housing shape and sleeve material
DIN to SC | SC to ST | SC to FC | DIN to FC |
| FC to ST | LC to FC | LC to SC | |
SPECIFICATIONS (SC, LC, FC, ST, MU, D4, DIN adapter)
ITEM | PARAMETER |
| Applicative adapter type | SC,LC,FC,ST,MU,D4,DIN |
| Fiber mode | Single mode | Multi-mode |
| Adapter color | Blue, green, metal | Beige, metal |
| Test wavelength | 1310nm, 1550nm | 850nm, 1300nm |
| Insertion Loss | typical≤0.15dB,Max≤0.20dB | typical≤0.15dB,Max≤0.20dB |
| Repeatability | ≤0.10dB |
| Interchangeability | ≤0.20dB |
| Durability | ≤0.20dB Max change,1000 mating |
| Channels | Simplex,Duplex,4channels |
| Body material | Plastic or metal |
| Sleeve material | Ceramic(ZrO2) |
| Operating Temperature | -20ºC to +70ºC |
| Storage Temperature | -40ºC to +85ºC |
SPECIFICATIONS
Insertion Loss | <0.20dB for 2.5sleeve to 2.5sleeve, |
| Durability | <0.20 dB typical change, 1000 matings |
| Operating Temperature | -40 to + 85°C
|
