Name: Fiber Optic Cable GYTS Outdoor 48 Core Fiber Optic Cable
Brand: all-electronics-online.com
SKU: 823341895
Availability: InStock
Rating: 5 (40 reviews)

Price:	US $ 43-45/Roll
Min Order:	100/Roll
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GYTS Outdoor 48 Core Fiber Optic Cable
Application:	Medicine
Type:	Single-mode Fiber
Connection Structure:	SC
Certification:	ISO9001

Product Description

Product Description
GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable Details:

Product Description
This GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable has been designed for long haul / backbone application. Our stranded loose tube design provides stable performance over a wide temperature range and is compatible with any telecommunication grade optical fiber. GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable are designed for easy and economical installation.

GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable Features:
Excellent optical, mechanical & environmental performance
High strength-to-weight ratio
High tensile strength
High crush strength
Corrosion resistance
Very light weight
Very flexible bending radius

GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable Application
Long haul / backbone application

GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable Technical data:

Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Min. Bending radius(mm)		Tension (N)		Crash loading (N/100mm)
Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Static	Dynamic	Short term	Long term	Short term	Long term
2-30	9.8	95	10 times O. D.	20 times O. D.	1500	600	1000	300
32-36	10.3	115
38-60	10.7	115
62-72	11.3	140
74-96	12.9	175
98-120	14.4	210
122-144	15.8	245
146-216	16.3	260
218-240	19.5	345
242-288	21.7	415

GYTS Outdoor Aerial and Duct 48 Core Fiber Optic Cable Packaging Detail:
GYTS 2-288 Core Optical Fiber Cable package are wooden drum. Outdoor 2-288 Core Optical Fiber Cable's wooden dimension is 100cm*75cm*75cm, 0.57CBM
Outdoor cable's delivery length according to 2-288 Core Optical Fiber Cable cores. Also accept custom cabledrum from customers.
