Fiber Optic Multimode Pigtail Sc/Upc Connector

Fiber Optic Multimode Pigtail Sc/Upc Connector
Price: US $ 0.1-1.5/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 100/Piece
Pay Type: L/C,T/T,Paypal,Western Union
Prod Model: SC/UPC Fiber Optic Pigtail
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Length: 1.5m, 2m, 3m ... Is Optional
Fiber Type: 50/125, 62.5/125
Type: Multi-mode Fiber
Connection Structure: Sc/Upc
Allowed Lateral Pressure: >1000(N/100mm)
Core: Multicore
Certification: CE, RoHS
Sheath Material: Lszh
Brand: Daytai
Connector Type: Sc/Upc
Application: Sensor

Product Description


Description
Fiber optic pigtail, MM, 50/125or 62.5/125, 0.9mm, LSZH, Length: 1.5m, 2m, 3m...is optional, SC/UPC Connector.
Features
* High Reliability
* High Return Loss
* Low Insertion Loss
 Application
* Telecom Net
* Local Ring Net
* Optical Fiber Sensor
* Optical FiberTest Equipment
* Optical Fiber Communication System
* FTTH, LAN, PON& Optical CATV.
Performance

ITEM

Specification

SM

MM

SC/UPC

SC/UPC

Insertion  Loss

≤0.20dB

Max.  Insertion Loss

≤0.30dB

Return  Loss

45

~

Fiber  Type

9/125

    50/125,62.5/125

Core  Number

Single or Dual Fiber

Durability

>1000 Times

Operation Temperature

-25~+70ºC

Storage  Temperature


-40~+85ºC
