FTTH Indoor LSZH Self-Supporting Drop Fiber Optic Cable

Prod Model:	FTTH
Model No:	FTTH Optical Cable
Fiber Count:	1-4core
Brand Name Of Fiber:	Corning ,Yofc,Draka, Fujikura...as Requirement
Color Of Loose Tube:	Blue, Orange, Green, Brown
Strength Member:	Steel or FRP
Jacket Color:	Black, White
Installation:	Indoor & Outdoor Self-Support Drop Cable
Range Of Temperature:	-20°c~+60°c
Cable Dimension:	3.1*2.0mm
Cable Weight:	8.2kg/Km
Application:	Optical Cable
Certification:	Reach,Tlc,etc
Type:	Single-Mode or Multimode Fiber
Connection Structure:	Optical Cable
Allowed Lateral Pressure:	Long Term:1100n; Short Term:2200n
Allowed Tensile Strength:	Long Term:300n; Short Term:600n
Core:	1-4 Core Optical Cable
Brand:	Tw-Scie or OEM
Sheath Material:	LSZH PE

Product Description

FTTH Indoor LSZH Self-Supporting Drop Fiber Optic Cable




Application:
1. Adopted to indoor distribution.
2. As pigtail of communication equipment
3. Suitable for communication equipment
4. Can be installed conveniently

Characteristics:
1. Weight, low cost, and practicability.
2. Suitable for limited space field of the branch, indoor series
3. Laid to facilitate construction operations;part and the cable
4. Jacket use low smoke, halogen-free flame-retardant materials.
5. Prevent lightning and strong electric environment;
6. FRP or KFRP strengthen the component materials.

 Cable construction details :


Items			Description
Number of fiber			1core
Fiber	type		G657A
	diameter		250µm
Strength member	material		Galvanized steel wire/FRP/KFRP
Cable sheath thickness	/		Max. 0.8mm/Min. 0.4mm
	/		/
Outer sheath	material		LSZH
	diameter		1.8±0.2mm
Cable size (Height * width)			3.0(±0.1) mm ×2.0 (±0.2)mm
Cable weight			8.5 KG±1KG
Installation Temperature range(ºC)			-20+60
Operation and transport temperature(ºC)			-40+70
Min Bending Radius(mm)		Long term	10D
Min Bending Radius(mm)		Short term	20D
Min allowable Tensile Strength(N)		Long term	40
Min allowable Tensile Strength(N)		Short term	80
Crush Load (N/100mm)		Long term	500
Crush Load (N/100mm)		short term	1000



Fiber characteristic


Fiber style		Unit	SM  G652	SM G652D	MM 50/125	MM 62.5/125	MM OM3-300
condition		nm	1310/1550	1310/1550	850/1300	850/1300	850/1300
attenuation		dB/km	≤	≤	≤	≤3.0/1.0	≤3.0/1.0
			0.36/0.23	0.34/0.22	3.0/1.0	----	----
Dispresion	1550nm	Ps/(nm*km)	----	≤18	----	----	Dispresion
	1625nm	Ps/(nm*km)	----	≤22	----	----
Bandwith	850nm	MHZ.KM	----	----	>=400	>=160	Bandwith
	1300nm	MHZ.KM	----	----	>=800	>=500
Zero dispersion wavelength		nm	1300-1324	>=1302, ≤1322	----	----	>= 1295, ≤1320
Zero dispresion slope		nm	≤0.092	≤0.091	----	----	----
PMD Maximum Individual Fibr			≤0.2	≤0.2	----	----	≤0.11
PMD Design Link Value		Ps(nm2*k m)	≤0.12	≤0.08	----	----	----
Fibre cutoff wavelength λc		nm	>= 1180, ≤1330	>=1180, ≤1330	----	----	----
Cable sutoff wavelength λcc		nm	≤1260	≤1260	----	----	----
MFD	1310nm	um	9.2+/-0.4	9.2+/-0.4	----	----	----
	1550nm	um	10.4+/-0.8	10.4+/-0.8	----	----	----
Numerical Aperture(NA)			----	----	0.200+/ -0.015	0.275+/-0. 015	0.200+/-0 .015
Step(mean of bidirectional measurement)		dB	≤0.05	≤0.05	≤0.10	≤0.10	≤0.10
Irregularities over fiber length and point		dB	≤0.05	≤0.05	≤0.10	≤0.10	≤0.10
Dicontinuity
Difference backscatter coefficient		dB/km	≤0.05	≤0.03	≤0.08	≤0.10	≤0.08
Attenuation uniformity		dB/km	≤0.01	≤0.01
Core dimater		um			50+/-1.0	62.5+/-2.5	50+/-1.0
Cladding diameter		um	125.0+/-0.1	125.0+/-0.1	125.0+/-0.1	125.0+/-0.1	125.0+/-0.1
Cladding non-circularity		%	≤1.0	≤1.0	≤1.0	≤1.0	≤1.0
Coating diameter		um	242+/-7	242+/-7	242+/-7	242+/-7	242+/-7
Coating/chaffinch concentrically error		um	≤12.0	≤12.0	≤12.0	≤12.0	≤12.0
Coating non circularity		%	≤6.0	≤6.0	≤6.0	≤6.0	≤6.0
Core/cladding conentricity error		um	≤0.6	≤0.6	≤1.5	≤1.5	≤1.5
Curl(radius)		um	≤4	≤4	----	----	----

Company Information
Dong Guan Tw-Scie Co., Ltd. Is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.

The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.

The main products of our enterprise are:
Optical fiber, optical cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.

All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.

Requirement for Order:
1. Fiber sort: Single mode G652,G655,G657, Multi mode 50/125,62.5/125,OM3,OM4.
2. Fiber brand: YOFC, Corning, Fiberhome Fujikura, OFS etc.
3. Sheath material: PE,LSZH, PVC( can be required).
4. Sheath color: Black ,can be required.
5. The fiber and tube color: according to stranded color, can be required.
6. The cable Size: shall be in accordance with the table, can be required.
7. Length of cable: generally is 2KM, can be required.
8. Other requirement:can be negotiated.

Package
1. Packing material: Wooden drum
2. Packing length: Customzied


Tag:
self supporting Figure 8 Drop cable
