FTTH Solutions Single Mode Fiber Optical Odc Connector

Name: FTTH Solutions Single Mode Fiber Optical Odc Connector
Brand: all-electronics-online.com
SKU: 836770635
Availability: InStock
Rating: 4.7 (48 reviews)

Price:	US $ 30/Piece
Min Order:	1/Piece
Pay Type:	L/C,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	UNWDM-TF-SC/UPC-LC/UPC-1
Application:	FTTH, Wdm Systems
Type:	Single-mode Fiber
Certification:	CCC
Connection Structure:	Sc-LC

Product Description

FTTH solutions Single Mode Fiber Optical ODC Connector

1. Product Overview

WDMs are based on thin film filter technology. They can be used in high-power applications in WDM systems. The products are used for dividing wavelengths into groups. One group is 1471/1491/1511/1531, the other is 1551/1571/1591/1611.

The products are Telcordia GR-1221-CORE qualified, and RoHS compliant.

2. Features

Low insertion loss
Low polarization dependent loss
Excellent reliability

3. Specification

No.	Parameter	Unit	Specification
3.1	Operating Wavelength	nm	1260~1620
3.2	Port number	PCS	3
3.3	Reflect Band Wavelength range	nm	1460~1537.5
3.4	Pass band wavelength range	nm	1544.5~1620
3.5	Insertion Loss	dB	≤1.2
3.6	Ripple over Pass Band	dB	≤0.5
3.7	Pass band Isolation	dB	≥15
3.8	Reflect band Isolation	dB	≥14
3.9	Insertion Loss Thermal Stability	dB/ºC	≤0.006
3.10	Wavelength Thermal Stability	nm/ºC	≤0.002
3.11	Return loss	dB	≥50
3.12	Directivity	dB	≥55
3.13	PDL	dB	≤0.25
3.14	PMD	PS	≤0.15
3.15	Power Handling	mW	300

Note: IL includes connector

4.Connector type

NO.	PARAMETER	SPECIFICATION	REMARK
5.1	Fiber Type	Corning SMF-28e with ¢2mm tube, color yellow	Or customer specified
5.2	Connector Type	Pass port (1551~1611): LC/UPC Reflect port (1471~1531): LC/UPC Com port: SC/UPC	Or customer specified
5.3	Fiber Length	Pass port (1551~1611): 1m Reflect port (1471~1531): 1m Com port: 1m	Or customer specified

Ordering Information

PN: UNWDM-TF-SC/UPC-LC/UPC-1

UNWDM	UNISKY Wavelength Division Multiplexing
TF	Thin Film Filter
SC/UPC	Com port Connector Type: SC/UPC
LC/UPC	Pass port & Reflect port Connector Type: LC/UPC
1	Com port & Pass port & Reflect port Fiber Length: 1M
