Full Automatic Compensation Voltage Regulators (SVC)

Name: Full Automatic Compensation Voltage Regulators (SVC)
Brand: all-electronics-online.com
SKU: 683456445
Availability: InStock
Rating: 4.4 (34 reviews)

Price:	US $ 98/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	5KVA, 10KVA,20KVA,30KVA,40KVA, 90KVA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color:	White
Current Type:	AC
Phase:	Three Phase
Usage:	SVC
Frequency:	Intermediate Frequency

Product Description

1. 380V voltage regulators / AC voltage / power voltage ----
6KVA, 9KVA, 15KVA, 20KVA, 30KVA, 40KVA, 50KVA, 60KVA, 90KVA

2. CE, ISO9002, SGS, CCC certificates, etc.

3. Features:
This series of voltage regulators with self-voltage regulation or compensation Surge, has features of small size, light weight, continuously adjustable voltage, output voltage and high precision, wide range of voltage regulation, low loss, no waveform distortion, which is widely used for civilian appliance regulators, industrial equipments, medical devices.

Input voltage	280-430, Ultra-low voltage230-430V
Output voltage	380± 3%
Phase	Three phase
Frequency	50-60Hz
Adjustment time	less than 0.5s, Input voltage change 10%
Rated output current	1.5KVA	3KVA	4.5KVA		6KVA	9KVA	15KVA	20KVA		30KVA	50KVA
	2A	4A	6A		8A	12A	20A	28A		40A	60A
Ambient temperature	-5 degree to 40 degree
Temperature rise	Less than 60 degree
Relative humidity	Less than 90%
Waveform distortion	No additional distortion
Efficiency	More than 90%
Pressure	Meet part standards
Model specifications				Machine size mm					Weight kg
SVC three-phase 1500VA				305× 560× 165					21
3000VA				350× 610× 185					26
4500VA				350× 610× 185					28
6000VA				280× 380× 670					43
9000VA				320× 380× 790					56
15000VA				435× 410× 780					83
20000VA				515× 460× 820					110
30000VA				510× 460× 990					131
50000VA				510× 800× 990					164
