Gear Motor for Packaging Machinery

Name: Gear Motor for Packaging Machinery
Brand: all-electronics-online.com
SKU: 774643295
Availability: InStock
Rating: 4.6 (28 reviews)

Price:	US $ 30/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	DC5GU60-120
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Voltage:	12V,24V,90V
Speed:	16-1100rpm
Torque:	0.6-20nm
Power:	60-120W
Application:	Power Tools
Operating Speed:	Low Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brush
Certification:	CE,Rosh
Brand:	Longway

Product Description

DC gear motor,

Typical Applications: Complete sets of transmission equipment,Automated
assembly line, Printing machinery, Packaging machinery

motor specification:

MODEL	VOLTAGE	POWER	NO LOAD		LOAD			BRUSH LIFE	MOTOR WEIGHT
	VOLTAGE	POWER	SPEED	CURRENT	SPEED	TORQUE	CURRENT	BRUSH LIFE	MOTOR WEIGHT
	V	W	RPM	A	RPM	kg.cm	A	H	kg
DC5GU60-12	12	60	3000	2.0	2600	2.3	9.0	3000	2.2
DC5GU60-24	24	60	3100	1.0	2800	2.1	3.5	3000	2.2
DC5GU60-90	90	60	3100	0.3	2900	2.0	1.0	3000	2.2
DC5GU90-12	12	90	3100	2.0	2600	3.4	12.0	3000	2.2
DC5GU90-24	24	90	3300	1.0	2800	3.2	5.0	3000	2.2
DC5GU90-90	90	90	3000	0.3	2800	3.2	1.4	3000	2.2
DC5GU120-12	12	120	3100	2.0	2500	4.7	15.0	3000	2.2
DC5GU120-24	24	120	3200	1.2	2600	4.5	7.0	3000	2.2
DC5GU120-90	90	120	3000	0.3	2600	4.5	2.0	3000	2.2

Model	Reduction Ratio		3	3.6	5	6	7.5	9	10	12.5	15	18	20	25	30	36	40	50	60
DC5GU90- 24	Output Shaft Speed	rpm	1100	916	660	550	440	366	330	264	220	183	165	132	110	91	82	66	55
	Allowable Torque	N.m	0.64	0.76	1.05	1.27	1.58	1.90	1.90	2.38	2.85	3.42	3.44	4.30	5.16	6.19	6.88	8.60	10.31
	Allowable Torque	kg.cm	6.53	7.75	10.76	12.92	16.12	19.37	19.40	24.25	29.10	34.92	35.08	43.85	52.62	63.15	70.16	87.70	105.24

Model	Reduction Ratio		75	90	100	120	150	180	200
DC5GU90-24	Output Shaft Speed	rpm	44	36	33	27	22	18	16
	Allowable Torque	N.m	12.89	13.83	15.37	18.44	19.60	19.60	19.60
	Allowable Torque	kg.cm	131.56	141.12	156.80	188.17	200.0	200.0	200.0

Ningbo Yinzhou Longway Technology Co., Ltd. is a professional motor, machinery and electronic products manufacturer in China. Since day one after its establishment, our company has spared no efforts in developing new products and optimizing them. A comprehensive and consistent quality system has been since long established, from design to production, form marketing to after sale service. Our company attaches great importance to employee training. It pays off when the quality of each and every one of our employees keeps improving. Now the motor products include PMDC motors, brushless motors, stepping motors, AC and DC gear motors, synchronous motors, brushless servo motors. Most of products are CE, UL approved. We can also complete OEM/ODM orders in accordance with clients' specific requirements, designs and samples.

The advanced technologies of design and manufacturing were adopted from Germany. We take pride in the CAD/cam mould tooling center and the testing center. We enjoy an excellent reputation in Europe, America, Australia, Middle East, and southeast Asia as well as in China.

"satisfactory products plus satisfactory services" makes our success happen. We sincerely hope to have and also thank for valuable supports and cooperation from all friends in the world.
