Good Performance LMR200 Coaxial RF Cable

Name: Good Performance LMR200 Coaxial RF Cable
Brand: all-electronics-online.com
SKU: 749251255
Availability: InStock
Rating: 4.4 (45 reviews)

Price:	US $ 0.3-0.5Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	50box
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	LMR200 Coaxial Cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Conductors:	1
Shielding:	Foil + Braided
Application:	RF Cable
Conductor Material:	BC/CCS/CCA/TC/CU/CCAG
Cover Material:	PVC
Certification:	RoHS
Model:	LMR200 Coaxial Cable
Brand:	Daytai
Type:	LMR Coaxial Cable

Product Description

Description
LMR 200 Coaxial Cables, Inner Conductor:1.12mm+Dielectric:2.95mm+First Shield:3.07mm+Second Shield:3.66mm+Jacket:4.95mm.Packing:100M or 305M Wood Spool.

Electrical Characteristics

Item
Impedance(Ω)	50±2
Capacitance(pF/m)	101.10
Velocity of Propagation(%)	66.00
Min Screening Effectiveness(dB)	>=90
Inner Conductor DCR(Ohm/km)	266.00
Outer Shield DCR(Ohm/km)	31.20
Voltage Withstand(Volts DC)	500.00
Spark Test(VRMS)	2000.00
Installation Temp Range(ºC)	-40ºC~70ºC
Operating Temp Range(ºC)	-40ºC~70ºC

Attenuation (@20%)

Max Attenuation(dB/100m)	Frequency
	50MHz	16.7
	150MHz	29.4
	220MHz	35.8
	450MHz	51.9
	900MHz	74.9
	1500MHz	98.7
	1800MHz	109.0
	2000MHz	115.0
	2500MHz	130.8
	5800MHz	210.3
VSWR
VSWR Max	800~2500MHz	1.20
	100~480MHz	1.15
	800~1900MHz	1.15
	1900~2500MHz	1.18
