Green Solder Mask PCB Board Copper Substrate High Voltage Test

Name: Green Solder Mask PCB Board Copper Substrate High Voltage Test
Brand: all-electronics-online.com
SKU: 831632735
Availability: InStock
Rating: 5 (57 reviews)

Price:	US $ 2.65/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-577-V5.77
Aluminum Core:	1W / Dielectric Material
Thermal Resistance(°c/W):	<=0.45
Breakdown Voltage(VDC):	4000
Final Foil External:	1 Oz
Final Height Of PCB:	1.6mm
Surface Finish:	Electroless Nickel Over Immersion Gold (Enig)
Solder Mask Color:	White, Taiyo Psr400 Wt02
Colour Of Component Legend:	No Silkscreen Required
Via:	No Via
Test:	100% Electrical Test Prior Shipment
Type:	Rigid Circuit Board
Flame Retardant Properties:	V0
Material:	Aluminum
Dielectric:	Aluminum 5052

Product Description

Company Profile
Bicheng Enterprise Limited mainly specializes in high frequency and microwave printed circuit
boards. We have rich experiences on the high frequency PCB in the application of power divider,
coupler, combiner, power amplifier, trunk amplifier, base station and 4G antenna etc. The dielectric
constant ranges from 2.2-10.3 etc. We keep inventory at any time for RO4350B, RO4003C,
F4B etc. and can provide quick sample service in time.
We're capable of supplying high frequency PCBs up to 32 layers inclusive of HDI technology, blind
and buried via, hybrid with FR-4 substrate etc.

Aluminum PCB

High Frequency PCB

Flex PCB

PCB Circuit Board

The components of multilayer PCB: thin laminates
A multilayer board consists of copper foils, thin rigid laminates and prepreg sheets.

Thin laminates are used for inner cores and are available in so many different thicknesses that
almost any specified build-up can be accomplished.

Different thickness of thin laminates

mm	mils	mm	mils
0.050	2	0.360	14
0.075	3	0.410	16
0.100	4	0.460	18
0.125	5	0.510	20
0.150	6	0.560	22
0.175	7	0.610	24
0.200	8	0.660	26
0.250	10	0.710	28
0.300	12	0.760	30

The thicknesses are valid for the bare laminate, with the copper foil being excluded. We can see
the cores are quite thin. For a total thickness of 1.6mm (0.063inch) board, the more layers, the
thinner the laminates should be. See our reference Multilayer PCB stackup for 0.063inch thick.
