Gwiec Best Trading Products Lp1-D Series DC Operated 9A AC Contactor 380V

Name: Gwiec Best Trading Products Lp1-D Series DC Operated 9A AC Contactor 380V
Brand: all-electronics-online.com
SKU: 827523435
Availability: InStock
Rating: 4.7 (96 reviews)

Price:	US $ 1.9-2.5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	LP1-D
Standard:	Ce/IEC60947-4-1
Design:	Can Combined with The Auxiliary Contact Block, Tim
Application:	for Controlling Circuit Making,Breaking and Starti

Product Description

Application:

LP1-D series DC operated AC contactor is suitable for use in the circuits up to rated voltage 660V AC 50Hz or 60Hz,and in rated current 9-95A in AC-3/380V load circuits
It for remote controlling circuit making,breaking and frequent starting AC motors
It can also combine with the auxiliary contact group,air delayer,thermal relay devices etc

Specification:
Specification:

Type			LP1-D09	LP1-D12	LP1-D18	LP1-D25	LP1-D32	LP1-D40	LP1-D50	LP1-D65	LP1-D80	LP1-D95
Rated working current(A)	380V	AC3	9	12	18	25	32	40	50	65	80	95
	380V	AC4	3.5	5	7.7	8.5	12	18.5	24	28	37	44
	660V	AC3	6.6	8.9	12	18	21	34	39	42	49	55
	660V	AC4	1.5	2	3.8	4.4	7.5	9	12	14	17.3	21.3
Rated heat current(A)			25	25	32	40	50	60	80	80	125	125
Controllable power(kW)	220/240V		2.2	3	4	5.5	7.5	11	15	18.5	22	25
	380/400V		4	5.5	7.5	11	15	18.5	22	30	37	45
	415V		4	5.5	9	11	15	22	30	37	45	45
	500V		5.5	7.5	10	15	18.5	22	30	37	55	55
	600/690V		5.5	7.5	10	15	18.5	30	33	37	45	55
Weight(Kg)	DC contactor		0.64	0.34	0.65	0.65	0.95	2.185	2.185	2.185	2.525	2.525
Measure(Mm)3	DC contactor		76x115 x47	76x115 x47	76x120 x47	76x130 x59	86x135 x59	128x175 x81	128x175 x87	128x175 x87	128x183 x87	128x183 x87
Pole			3,4	3,4	3	3,4	3	3,4	3,4	3,4	3,4	3,4
Rated working voltage(V)			380,660
Rated insulation voltage(V)			660
Mechanical life x104			1000	1000	1000	1000	800	800	800	800	600	600
Electrical life	AC3x104		100	100	100	100	80	80	80	80	60	60
Electrical life	AC4x104		20	20	20	20	20	15	15	15	10	10
Operating frequency	Electrical life	AC3x104	1200	1200	1200	1200	600	600	600	600	600	600
	Electrical life	AC4x104	300
	Mechanical life x104		3600
Rated controlled voltage (V)			24-660
Working voltage	Close	DC%	0.85-1.1Us
Working voltage	Open	AC%	0.10-0.75Us

outline and mounting dimension:

Type	AMAX	BMAX	CMAX	DMAX	EMAX	a	b	φ	L	P	S
LP1-D09~12		74				35	50/60	4.5
LP1-D18	47	76	82(116)	120.5(154.5)	140.5(174.5)	34/35	50/60	4.5	60	105	8.6
LP1-D25~32	57	86	95(131)	133.5(169.5)	153.5(189.5)	40	48	4.5	70	13.2	11.7
LP1-D40~65	77	129	116(173)	154.5(211.5)	174.5(231.5)	40	100/110	6.5	78	20	8.6
LP1-D80~95	84	129	116(173)	154.5(211.5)	174.5(231.5)	40	100/110	6.5	78	20	8.6
LP1-80~95	96	129	127(183)	160.5(221.5)	180.5(241.5)	40	100/110	6.5	83	23.5	12
