H05V-U, H05V-R, H05V-K PVC Insulated Electrical Cable Wire
| Price: |
US $ 0.1/Meter |
| Min Order: |
100/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
electrical cable wire |
| Product Name: |
H05V-U, H05V-R, H05V-K Electrical Wire |
| Origine: |
Shandong, China |
| Rated Voltage: |
300/500V 450/750V |
| Core Number: |
Single Core |
| Conductor: |
Copper |
| Insulation: |
PVC / XLPE |
| Certificates: |
ISO, CCC, Ce . RoHS |
| MOQ: |
100 Meter |
| Shipping: |
by Sea, by Air, by Train |
| Package: |
100 Meter Per Roll |
| Type: |
Insulated |
| Conductor Material: |
Copper |
| Insulation Material: |
PVC |
| Certification: |
GB/T |
| Conductor Type: |
Solid / Stranded |
| Application: |
House Wiring Cable |
| Sheath Material: |
Non |
| Range Of Application: |
Lsoh / Flame Retardant |
| Brand: |
Chang Qing Teng |
Product Description
300/500V H05V-U,H05V-R,H05V-K PVC insulated electrical cable wire
Application:
Fixed protected installation inside appliances and in, or on, lighting fittings.
Suitable for installation in surface mounted or embedded conduits, only for signalling or control circuits.
Conductor: acc. to IEC 60228
annealed copper,
class 1 solid (H05V-U),
class 2 stranded (H05V-R)
class 5 flexible (H05V-K)
Insulation:
PVC compound type TI 1 n Pb
Colour of insulation:
green/yellow, blue, black, brown or other colours
Maximum conductor operating temperature: +70°C
Lowest ambient temperature for fixed installation (static): -30°C
Lowest installation temperature (flexing): -5°C
Maximum short-circuit conductor temperature: +160°C
Test voltage 50Hz: 2000V
Flame propagation: IEC 60332-1-2
Minimum bending radius: 4 x cable diameter
Specifications
H05V-U 300/500V Single core PVC insulated non sheathed cables for general purposes
Solid copper conductor
| Conductor cross section | minimum wall-thickness | Outer Diameter min. - max. | Weight approx. | Conductor DC resistant at 20°C | Standard
length |
| mm² | mm | mm | kg / km | Ω/km | m /coil |
| 0.5 | 0.6 | 1.9 - 2.3 | 9 | 36 | 100 |
| 0.75 | 0.6 | 2.1 - 2.5 | 12 | 24.5 | 100 |
| 1 | 0.6 | 2.2 - 2.7 | 15 | 18.1 | 100 |
H05V-R 300/500 V Single core PVC insulated non sheathed cables for general purposes
Stranded copper conductor
| Conductor cross section | minimum wall-thickness | Outer Diameter min. - max. | Weight approx. | Conductor DC resistant at 20°C | Standard
length |
| mm² | mm | mm | kg / km | Ω/km | m /coil |
| 0.5 | 0.6 | 2.0 - 2.4 | 9 | 36 | 100 |
| 0.75 | 0.6 | 2.2 - 2.6 | 12 | 24.5 | 100 |
| 1 | 0.6 | 2.3 - 2.8 | 15 | 18.1 | 100 |
H05V-K 300/500 V Single core PVC insulated non sheathed cables for general purposes
Flexible copper conductor | Conductor cross section | minimum wall-thickness | Outer Diameter min. - max. | Weight approx. | Conductor DC resistant at 20°C | Standard
length |
| mm² | mm | mm | kg / km | Ω/km | m /coil |
| 0.5 | 0.6 | 2.1 - 2.5 | 9 | 39 | 100 |
| 0.75 | 0.6 | 2.2 - 2.7 | 12 | 26.0 | 100 |
| 1 | 0.6 | 2.4 - 2.8 | 15 | 19.5 | 100 |
