High Frequency Modified Sine Wave DC 12V to AC 220~240V 600W LCD Home Power Inverter
| Price: |
US $ 70/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,Western Union,Money Gram |
| Prod Model: |
IG1000-C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Phase & Waveform: |
Single&Modified Sine Wave Inverter |
| Input: |
12/24 or 110/120/220/230/240 |
| Charger: |
8/10A |
| Peak Power: |
2 Times |
| Efficiency: |
80% |
| Display: |
LED /LCD |
| Off Mode Charging: |
Yes |
| Power Factor: |
0.6 |
| Phase: |
Single |
| Brand: |
Zlpower |
Product Description
High frequency modified sine wave dc 12v to ac 220~240v 600W LCD home power inverter
1.Applications:
It is mainly used for home appliances and small office equipments.
2.Main Features:
1) Advanced MCU microprocessor control technology make it full automatic and silent operation with Intelligent speed fan to release heat.
2) Modified sine wave output.
3) User selectable for wide or narrow input voltage range as it said on the spectation table.
4) Rack Tower design with compact size make it convenient to use and storage .
5) Built-in 10Amp super charger for up to 200Ah battery, off charging mode, even inverter not start, it can still charge.
6) Multi-functional LED indicator light and alarm device.
7) Cost-effective and sutable for home appliances and small office equipments
3.Detail technical parameters for 500VA-2000VA IG series home inverter.
| LCD MODEL | IG500-C | IG1000-C | IG1000-24-C | IG2000-24-C |
| LED MODEL | IG500 | IG1000 | IG1000-24 | IG2000-24 |
| CAPACITY | VA/W | 500VA / 300W | 1000VA/600W | 1000VA / 600W | 2000VA / 1200W |
| INPUT | Phase | Single phase |
| Norminal Voltage | 110/120VAC OR 220 /230/240VAC |
| Voltage Range | 90-145VAC OR 170-280VAC(Narrow) |
| 50-145VAC OR 90-280VAC(Wide) |
| OUTPUT | Phase | Single phase |
| Voltage | 120VAC OR 230VAC |
| Voltage Regulation(Batt. Mode) | 10% or -18% |
| Frequency | 50Hz or 60Hz |
| Frequency Regulation (Batt. Mode) | ± 0.1 Hz |
| Output Waveform (Batt. Mode) | Modified Sine Wave |
| POWER FACTOR | P.F. | 0.6 |
| BATTERY | DC Voltage | 12V | 12V | 24V | 24V |
| Charger Current | 8 A ± 1Amp | 8 A ± 1Amp | 10 A ± 1Amp | 10 A ± 1A |
| Floating Voltage | 13.7V ± 0.2V | 13.7V ± 0.2V | 27.4V± 0.4V | 27.4V± 0.4V |
| Overcharge Protection | 15V ± 0.3V charger stops and fault | 15V ± 0.3V charger stops and fault | 30V± 0.6V charger stops and fault | 30V± 0.6V charger stops and fault |
| TRANSFER TIME | Typical | 15ms Typical ,50ms Max |
| EFFICIENCY | AC to DC | >98% |
| DC to AC | >80% |
| INDICATOR | AC Mode | Green LED lighting |
| Battery Mode | Yellow LED lighting |
| Battery Charging Mode | Green LED flashing every 2 seconds |
| Overload | Red LED flashing every 0.5 second |
| Fault | Red LED lighting |
| AUDIBLE ALARM | Low Battery at Battery Mode | Sounding every 2 seconds |
| Overload | Sounding every 0.5 second |
| Fault | Continously sounding |
| PROTECTION | Full Protection | Deep Discharge, Overcharge, and Overload protection |
| PHYSICAL | Dimension (L x W x H) mm | 224 X 255 X 80 |
| Net Weight (kgs) | 1.7 | 2.3 | 2 | 2.5 |
| ENVIRONMENT | Operating Environment | 0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing) |
| Noise Level | Less than 50dB |
About ZLPOWER
Founded in 2007, Shenzhen ZLPOWER Electronics Co., Ltd. (ZLPOWER for short) is a key hi-tech enterprise in state "Torch Plan, " integrating science, industry, trade, and investment into a whole. It has registered capital of RMB 10million, covering a floor area of 2000sq. M, and owning assets of RMB 30 million.
As a large-scale enterprise group with total assets exceeding RMB 30 million, it currently employs more than 300 staff, operates R & D institutions, 10 products lines, and 8 overseas branches and offices for sales and service.
Also as a professional uninterruptible power supply manufacturer in Shenzhen, China, ZLPOWER mainly produce high frequency online UPS, computer PC UPS, rack mount online UPS, low frequency Industry three phase UPS, UPS Inverter, solar inverter, solar charger controller, Solar/UPS Battery and other related products.
In ZLPOWER, we are strictly on quality inspections. We implement strict IOC, IPQC, FQC, OQC, QA, and other quality control measures in every process according to ISO9001, including to raw materials selection, production, package, and shipment.
Thus, we are ISO9001: 2008 and SGS certificated, and all our UPS, Inverter power supply products have been approved by CE (LVD/EMC), UL tests. As a result, they are popular among our customers from Italy, Germany, South Africa, Egypt, Mozambique, Nigeria, UAE, Ukraine, Russia, Uzbekistan, Philippines, Chili, Peru, Brazil, Mexico and more.
ZLPOWER is looking for agent worldwide to distribute our quality UPS system, Inverter power and solar products to their local markets. Any interests please welcome to contact us today and look for best power solution.
