High Performance Self-Supporting Aerial Gytc8s Fiber Optic Cable
| Price: |
US $ 0.03-0.15/Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
5000/Meter |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
| Prod Model: |
GYTC8S Fiber Optic Cable |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
Gytc8s Fiber Optic Cable |
| Fiber Color: |
Nature,Blue,Red,Green, |
| External Sheath: |
PE |
| Mode: |
Single or Multimode |
| Number Of Conductors: |
More Than 10 |
| Tube: |
Standed Loose Tube |
| Strength: |
Metallic Central Strength |
| Core Material: |
Steel Wire |
| Application: |
Aerial Application, Outdoor Distribution |
| Certification: |
ISO9001 |
| Brand: |
Daytai |
| Core: |
24/48/72/96.. Core Fiber Optic Cable |
| Sheath Material: |
PE |
| Type: |
Single Fiber or Multimode Fiber |
| Material Shape: |
Fig8 |
Product Description
Self-Supporting Aerial GYTC8S Fiber Optic Cable
Fiber Optic Cable Characteristics:
1. PE Sheath
2. Metallic central strength, loose and layer-stranded tube style
3. Single mode and multi-mode
Fiber Optic Cable Specification:
1. Application: Aerial
2. Mode: Single mode and multi-mode
3. Strength Member: Metallic central strength
4. Sheath Material: PE
5. Operating Temperature (° C): -40~+60
6. CE, UL, ROHS standard
7. MOQ: 4 KM
8. OEM service
9. Sample is available
10. Delivery time: 7~15 days, according to your quantity
11. Payment terms: T/T, L/C, D/P, Western union
12. FOB Port: Shanghai, Ningbo
Fiber Optic Cable Application:
1. Long-distance and interoffice communication
2. Adopted to Outdoor distribution
3. Aerial applications
Fiber Optic Cable Feature:
1.100% cable core filling
2. High strength loose tube that is hydrolysis resistant
3. Good performance of tensile strength and temperature
4. Loose tube filling compound
5. Crush resistance and flexibility
6. High water resistance
7. Self-supporting aerial wiring with the span of 100m or below
Fiber Optic Cable Basic Construction
|
Fiber count |
6, 12, 24 |
36 |
48,60 |
72 |
~144 |
|
Max. cores in tube |
6 |
6 |
12 |
12 |
12 |
|
Element number |
5 |
6 |
5 |
6 |
~12 |
|
Cable diameter (MM) |
9.8 |
10.3 |
10.8 |
11.4 |
~16.5 |
|
Weight (KG/KM) |
200 |
210 |
220 |
240 |
280 |
|
Tensile strength (N) |
(5KN~10KN) According to the demand of design |
|
Crush Resistance (N/100MM) |
Long term |
300 |
|
Short term |
1000 |
|
Bending Radius (MM) |
Dynamic |
≥20 * Cable diameter |
|
Static |
≥10 * Cable diameter |
|
Operating Temperature (°C) |
-40~+60 |
|
Application |
Aerial |
