| Function: |
Temperture Control |
Product Description
WKB Capillary Termostat
The Termostat shown in the picture is a kind of universal Capillary Termostat applied in a number of electrical appliances. According to the customized specifications, it could be made to control temperature from -35 deg C to +320 deg C. More technical information of this Capillary Termostat will be shown in the table below.
Features of WKB Capillary Termostat
1.Strictly comply with UL, CE, CQC, RoHS
2.Available in a wide temperature range and differential
3.Temperature adjustable through adjusting shaft
4.Auto-reset, manual-reset, and fixed temperature design available
5.Snap-Action electric switch
6.Little magnetic interference
7.Long life usage
8.Accessories, such as knob, bezel, capillary gland kit etc. available
9."D" shaped adjusting shafts with different lengths are available according to a variety of electrical appliances
Specification of WKB Capillary Termostat
| Temperature Rangeof Capillary Termostat | -35°C~ +320°C |
| General Temperature Range | +0°C~+40°C
+30°C~+85°C
+30°C~+90°C
+30°C~+110°C
+30°C~+185°C
+50°C~+300°C
+50°C~+320°C |
| Temperature Differential | 5% of Action Temperature |
| Length of Capillary | 300mm~3000mm optional |
| Material of Capillary and Sensing Bulb | Stainless Steel and Copper optional |
| Diameter of Sensing Bulb | 3mm,4mm,5mm,6mm |
| Electric Rating | 16(3)A 250VAC~10(1.8)A 400V |
| Wiring Diagram | Single PoleSingle Throw (SPST)
Single Pole Double Throw (SPDT) |
| Material of Terminal | Brass |
| Mounting Hole | 2-M4 |
| Center of Mounting Hole | 28mm |
| Min. Capillary Bend Radius | 5mm |
| Temperature's Rate of Change | 1°C/min |
| Life | 100000 cycles |
Capillary Thermostat, Heater Thermostat, Heating Capillary Thermostat, Termostato, Termostat, Stat, Temperature Controller, Switches, Temperature Switch, Thermal Switch, Sensor, Heater Thermostat, Heater, Water Thermostat, Water Heating System, Oven Thermostat, Temperature Thermostat, Heating Thermostat, Heat Pump Thermostat, Capillary Thermostat, Adjustable Thermostat, Thermal Protector, Room Thermostat, Mechanic Thermostat, Thermocouple, Thermometer, Thermostat Wiring, HVAC, HVAC Thermostat,
| TemperatureRange of Capillary therostat: | -35°C ~ +320°C |
| Electric Rating: | 16 ( 3 ) A - 250V ~ 10( 1.8 ) A - 400V |
| Min. Current: | 200mA |
| Electrical Strength: | AC 2000V/1min |
| Normal Insulation Resistance: | ≥100MΩ |
| Wet Insulated Resistance: | ≥10MΩ |
| Contact Resistance: | ≤50MΩ |
| Temperature Response Rate: | ≤1.0°C/min |
| Life (Cycles) of heating capillary thermostat: | ≥100,000 |
| WIRING FORM: | S.P.S.T or S.P.D.T |
Specifications of Heater capillary thermostat:
| | Sensing Bulb | Capillary |
| Specification | Dia.:
Φ3,Φ4,Φ5,Φ6 | Standard: 700mm
(300~3000mm optional) |
| Material | Copper, Stainless Steel | Copper, Stainless Steel |
Temperature Switch, Temperature Sensor, Regulator, Terminal, Heating Element, SPDT, KSD, KST, Bimetal Thermostat, Thermtrol, Capillary Thermostat Switch, Thermal Cutoff, Thermal Circuit Breaker, Bulb Thermostat, Probe Thermostat, Fryer, High Limit Thermostat, Heating Control thermostat, Best Thermostat, ECO Thermostat, Thermostat7, Control Valve, Oven Switch, Thermo Control, Thermal Cutout, Thermal Regulator, Oven Component, High Limit Thermostat,
Packaging & Delivery
| Packaging Details: | Standard: 200 pieces of capillary thermostats per carton box (44.5cm*38.5cm*26cm; G.W. 19KG)
Nonstandard: negotiable |
| Delivery Detail: | Within 20-30 days after down payment received |
WK Series Thermal Cut-Out/Thermal Cut Out/Thermal Cutoff Switch
· Approved by UL,CE,RoHS,CQC certifications
· Highly competitive price offered
· Small MOQ
· Standard strong package for export. Nonstandard package available.
· Large daily output of capillary thermostat
· Experienced R&D, and conscientious managent for support
Features of WKB Water Heater Thermal Cut-Out
| Temperature Range of Thermal Cut-Out | -35~320°C(-31~608°F) |
| Action Temperature of Thermal Cut-Out | Available on requests from customers |
| Electric Rating of Thermal Cut-Out | AC 400V 10A~250V 16A |
| Working Life of Thermal Cut-Out | 100,000 cycles |
| Contact | SPST & SPDT optional |
| Accessories | Adjustment knob, bezel and mounting screws can be supplied completely |
Specifications of WKB Water Heater Thermal Cut-Out
| | Sensing Bulb | Capillary |
| Specification | Dia.:
Φ3,Φ4,Φ5,Φ6 | Standard: 1000mm
(300~3000mm optional) |
| Material | Copper, Stainless Steel | Copper, Stainless Steel |
| Specifications are available on customers' requests |
Applications of WKB Water Heater Thermal Cut-Out
· Heater
· Electric & gas oven
· Deep fryer
· Vending equipment
· Refrigerator & freezer
· Food service equipment
· Agricultural equipment
· Environment controls
· Livestock warmer
· Incubator
· Hatcher
