High Quality Insulated, 18AWG PVC Electrical Wire, 105 Degree

Name: High Quality Insulated, 18AWG PVC Electrical Wire, 105 Degree
Brand: all-electronics-online.com
SKU: 831208195
Availability: InStock
Rating: 4.4 (130 reviews)

Price:	US $ 0.021-0.05/Meter
Min Order:	6100/Meter
Pay Type:	Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	1015
Type:	Insulated
Conductor Type:	Stranded
Insulation Material:	PVC
Certification:	CSA, Ts16949
Application:	Home Application,LED Lamp, Oven,Machine
Conductor Material:	Tinned Opper
Range Of Application:	Home Application,LED Lamp, Oven,Machine
Brand:	Mysun

Product Description

High quality insulated,18AWG PVC Electrical wire,105 degree

Product Description:

CSA Type	Conductor		Insulation thickness	Overall Diameter	Standard put-up		Conductor Resistance at 20°C
CSA Type	AWG	No./mm	mm	mm	ft/coil	m/coil	ohm/kft
UL 1015 (Stranded)	26	7/0.160	0.76	2.10±0.10	2000	610	45.20
	24	11/0.160		2.25±0.10	2000	610	29.30
	22	17/0.160		2.40±0.10	2000	610	16.70
	20	21/0.180		2.55±0.10	2000	610	10.50
	18	34/0.180		2.80±0.10	2000	610	6.64
	16	26/0.254		3.10±0.10	1000	305	4.18
	14	41/0.254		3.50±0.10	1000	305	2.62
	12	65/0.254		3.90±0.10	1000	305	1.65
	10	105/0.254		5.10±0.10	1000	305	1.04
UL 1015 (Top-coated)	22	7/0.254	0.76	2.38±0.10	2000	610	16.70
	20	7/0.320		2.55±0.10	2000	610	10.40
	18	7/0.404		2.80±0.10	2000	610	7.06
UL 1015 (Solid)	26	1/0.404	0.76	2.00±0.10	2000	610	43.53
	24	1/0.511		2.10±0.10	2000	610	27.25
	22	1/0.643		2.25±0.10	2000	610	16.50
	20	1/0.813		2.40±0.10	2000	610	10.30
	18	1/1.024		2.65±0.10	2000	610	6.25
	16	1/1.290		2.90±0.10	1000	305	4.10
	14	1/1.630		3.25±0.10	1000	305	2.57
	12	1/2.050		3.65±0.10	1000	305	1.62
	10	1/2.588		4.20±0.10	1000	305	1.02

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
