High Quality Miniature 4p Residual Current Circuit Breaker Pg430

Name: High Quality Miniature 4p Residual Current Circuit Breaker Pg430
Brand: all-electronics-online.com
SKU: 832915475
Availability: InStock
Rating: 4.4 (142 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	PG430
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Installation:	Fixed
Structure:	ELCB
Poles Number:	2
Certification:	CCC

Product Description

1.PG Residual Current Circuit Breaker/ RCCB
2.CE,ISO9001
3.OEM,ODM are avaliable
4.Warranty period:1 year
5.Fast deliver

PG Residual Current Circuit Breaker/ RCCB

Technical Specifications

Type	PG230	PG430
Poles	2P	4P
Rated Voltage (V)	250V/440V
Rated Current (A)	10,15,20,25,30,45,50,60A Adjustable
Leakage Motion Current (mA)	300mA, 500mA	300mA, 500mA
Leakage Dead Current (mA)	150mA, 250mA	150mA, 250mA
According with Standard	NFC61450

PG series adjustable residual current breaker(gardy rccb,gardy elcb)is suitable for AC 50/60Hz,230/400V circuit,prevents from overloading,short-circuit etc.On the occasion of shock hazard or earth leakage,it will trip immediately.At the same time,the rated current of overload protection can be adjustable.

CPG230, CPG430 Series breakers are suitable in AC 50Hz, 250/440V circuit with overload and earth leakage protection. The rated current is adjustable from 10A up to 60A. User can select suitable current to better protection against overload and short circuit. The products comply with NFC61450.

Residual Current Circuit Breaker
1.Stable high quality& Punctual delivery
2.Competitive price &professional service
3.Complied with CE and ISO9001
4.Strict QC Stable Quality

ZHEJIANG SHUNTONG Co., founded in 1995, with more than 35000M2 manufacturing space, 650 employees, it becomes one of the leading manufacturer of industrial electric product in China. As well as one of the earliest factories in the line with nearly 20 years experience in producing and developing for electric equipment.

The Company has successfully developed and producing various categories in industrial electric products which include: Circuit Breakers, Panel Boards, AC contactors, Meters, Relays, Fuses, Control Units… As well as many other electrical accessories such as LED lighting.

Shuntong owns modern R&D center for developing electric products with full-line of high-tech moulding, manufacturing equipment and great strength of technical support, besides advanced design forces powered by first class engineering teams with super industrial computer systems. Thus, each piece of the product is fully assured with top-reliable quality, scientific and novel design as well as excellent workmanship.

SHUNTONG Electricals obtained ISO9001 quality system certification, ISO14001, OHSAS18001, CB certification; SEMKO and CE certification, etc. It is no doubt that the products are warmly welcomed not only in domestic but also in overseas market year after year.

In order to keep the leadship in electrical industry, Shuntong continuous increase and update manufacturing facilities, keep improving techniques and adopting the most advanced inspect instrument to bring our products to an even higher quality level along with impeccable & rapidly delivery service.
