High Quality RGB LED Touch Controller

Name: High Quality RGB LED Touch Controller
Brand: all-electronics-online.com
SKU: 689242772
Availability: InStock
Rating: 4.4 (69 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	JA-CON-TRF8B(SJ)-3CH-LV
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max. Load Power:	288W
Connection Mode:	Common Anode
Application:	Audio / Video Players
Signal Transmission:	RF Remote Control
Type:	Button

Product Description

Specifications

It adopts advanced touch design, through the panel controller combination with touch remote way, realize flexible control

RF touch controller
RGB LED touch controller
Wireless touching controller

Summarization

This product is a novel LED controller developed by our company which can realize multistage touch dimmer.
Adopting advanced touch design, through the panel controller combined with touch remote way, realize flexiblecontrol. Touch remote has good performance, beautiful, fashion, easy to use. This product suit for every
Occasions, such as: Point light source, flexible strip, wall washer lamp, glass curtain wall light and such lighting
Controller.

Main feature

1. Touch-button, ultrathin, light quality, protable.
2. Touch-key count up to 64, up to 64 kinds of mode function, small volume, more key funcation.
3. Easy to use, have color pulley touch screen, all sorts of design and color mode at a glance, can a single point also can continuous touch to realize color mode select, users can speedily choose the needed color,
And the static and dynamic mode can change freely.
4. Auto dormancy function, the remote control is without buttons state more than 20 seconds, remote will
Automatic enter the standby state, realize save electricity, extending battery life.

Technical Parameters

Controller

Working temperature: -20-60° C
Supply voltage: DC5V, 12V, 18V, 24V optional(specify the required voltage on order form)
Output: 3 channels
Connection mode: Common anode
Static power consumption: <1W
Output current: ≤ 4A (each channel)
Output power: 5V: <60W, 12V: <144W, 24V: <288W

Touch remote control

Working temperature: -20-60° C
Power supply mode: AAA battery
Supply voltage: 1.5V*3
Static power consumption: 0.015mW
Standby current: 3uA
Work current: 300uA
Emission current: 10mA
Remote distance: 30m
Standby time: 6 months

Model Number: JA-CON-TRF8B(SJ)-3CH-LV	supply voltage: DC5V,12V,24
output: 3 channels	output current: 4A (each channel)
max. output power: 288W	remote distance: 30m
