High Temperature UL Certification VDE 8207, FEP Electrical Wire

Name: High Temperature UL Certification VDE 8207, FEP Electrical Wire
Brand: all-electronics-online.com
SKU: 839732315
Availability: InStock
Rating: 4.8 (82 reviews)

Price:	US $ 0.1-0.5/Meter
Min Order:	6100/Meter
Pay Type:	Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	8207
Type:	Insulated
Conductor Type:	Stranded
Insulation Material:	Teflon
Certification:	CSA , Iatf16949
Application:	Home Appliance, Head Lamp,Industrial Machine
Conductor Material:	Tinned Copper
Sheath Material:	FEP
Range Of Application:	Home Appliance, Head Lamp,Industrial Machine
Brand:	Mysun

Product Description

High temperature UL certification VDE 8207,FEP Electrical Wire

VDE 8207 Product dimensions:

Conductor			Insulation		Max.Cond Resistance (Ω/KM)	Unit length (M)(Ft)
Size (AWG)	Construction (No./mm)	Diameter (mm)	Nominal Thickness (mm)	Diameter (mm)	Max.Cond Resistance (Ω/KM)	Unit length (M)(Ft)
0.12	7/0.15	0.46	0.305	1.06	150.15	610/2000
0.20	7/0.20	0.60	0.305	1.21	89.3	610/2000
0.30	19/0.15	0.75	0.305	1.36	59.78	610/2000
0.50	19/0.19	0.95	0.305	1.56	40.1	305/1000
0.75	19/0.23	1.17	0.305	1.78	26.7	305/1000
1.00	19/0.26	1.31	0.305	1.91	20	305/1000
1.25	19/0.29	1.46	0.305	2.16	14.35	305/1000
1.50	19/0.32	1.61	0.305	2.31	13.7	305/1000
2.00	19/0.37	1.85	0.305	2.55	8.78	305/1000
2.50	19/0.41	2.06	0.305	2.76	7.16	305/1000
3.00	19/0.47	2.35	0.305	3.05	6.5	305/1000
4.00	19/0.52	2.60	0.450	3.50	4.7	305/1000
5.00	37/0.43	3.01	0.45	3.91	3.76	305/1000

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
