High Temperature UL1709, Teflon Insulated PFA Electrical Wires

Name: High Temperature UL1709, Teflon Insulated PFA Electrical Wires
Brand: all-electronics-online.com
SKU: 838300545
Availability: InStock
Rating: 5 (81 reviews)

Price:	US $ 0.021-0.05/Meter
Min Order:	6100/Meter
Pay Type:	Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	1709
Type:	Insulated
Conductor Type:	Stranded
Insulation Material:	Teflon
Certification:	Tsa, Itaf16949
Application:	Home Application,LED Lamp, Oven,Machine
Conductor Material:	Nickel Plated Copper Wire
Sheath Material:	PFA
Range Of Application:	Home Application,LED Lamp, Oven,Machine
Brand:	Mysun

Product Description

High Temperature UL1709,teflon insulated PFA Electrical wires

Conductor			Insulation		Max.Cond Resistance (Ω/KM)	Unit length (M)(Ft)
Size (AWG)	Construction (No./mm)	Diameter (mm)	Nominal Thickness (mm)	Diameter (mm)	Max.Cond Resistance (Ω/KM)	Unit length (M)(Ft)
0.12	7/0.15	0.46	0.305	1.06	150.15	610/2000
0.20	7/0.20	0.60	0.305	1.21	89.3	610/2000
0.30	19/0.15	0.75	0.305	1.36	59.78	610/2000
0.50	19/0.19	0.95	0.305	1.56	40.1	305/1000
0.75	19/0.23	1.17	0.305	1.78	26.7	305/1000
1.00	19/0.26	1.31	0.305	1.91	20	305/1000
1.25	19/0.29	1.46	0.305	2.16	14.35	305/1000
1.50	19/0.32	1.61	0.305	2.31	13.7	305/1000
2.00	19/0.37	1.85	0.305	2.55	8.78	305/1000
2.50	19/0.41	2.06	0.305	2.76	7.16	305/1000
3.00	19/0.47	2.35	0.305	3.05	6.5	305/1000
4.00	19/0.52	2.60	0.450	3.50	4.7	305/1000
5.00	37/0.43	3.01	0.450	3.91	3.76	305/1000

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
