High Voltage Silicone Wire UL3239 3kv, 6kv, 10kv

Name: High Voltage Silicone Wire UL3239 3kv, 6kv, 10kv
Brand: all-electronics-online.com
SKU: 836313845
Availability: InStock
Rating: 4.4 (36 reviews)

Price:	US $ 0.05-0.5/Meter
Min Order:	6100/Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	UL3239
Rated Voltage:	3kv, 6kv, 10kv
Rated Temp:	200c
Color:	White, Black, Red, Brown, Yellow, Blue etc
Type:	Insulated
Conductor Type:	Stranded
Conductor Material:	Copper
Insulation Material:	Silicone Rubber
Certification:	RoHS
Application:	Internal Wire
Range Of Application:	FT2
Brand:	Mysun

Product Description

Product dimensions:

Conductor			Insulation										Max.cond resistance (Ω/km)	Length (m)(Ft)
Size (AWG)	Construction (No./mm)	Diameter (mm)	3000V		6000V		10000V		20000V		30000V
Size (AWG)	Construction (No./mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)	Thickness (mm)	Diameter (mm)
28	7/0.12	0.37	0.50	1.37	0.70	1.77	1.00	2.37	1.30	2.97	1.70	3.77	227	305/1000
26	7/0.15	0.49		1.49		1.89		2.49		3.09		3.89	143
24	14/0.14	0.60		1.60		2.00		2.60		3.20		4.00	89.3
22	22/0.14	0.76		1.76		2.14		2.76		3.36		4.16	56.4
20	32/0.14	0.91		1.91		2.31		2.91		3.51		4.31	35.2
18	52/0.14	1.17		2.17		2.57		3.17		3.77		4.57	22.2
16	52/0.18	1.50		2.50		2.90		3.50		4.10		4.90	14

Service
Shipment:
1. by express
2. by sea

Payment terms:
LC, TT, Western Union, Money Gram and PayPal

Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working day

s

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
