Name: IEC 60947 Solar Energy Systems MCB Medium Voltage Minature Circuit Breaker
Brand: all-electronics-online.com
SKU: 837038905
Availability: InStock
Rating: 4.5 (128 reviews)

Price:	US $ 2.35-2.4/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	LFG60-63
Rated Current:	1A-63A
Rated Voltage:	230/400-240/415
Color:	White and Green
Rated Frequency:	50/60 Hz
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Installation:	Insert
Structure:	MCB
Poles Number:	3
Certification:	CE

Product Description

Model	FG65-125	FG60-63		F1-63
Standards	IEC/EN 60947-2	IEC/EN 60898-1	IEC/EN 60947-2	IEC/EN 60898-1
Rated Current(A)	63,80,100,125	1,2,3,4,6,10,16,20,25,32,40,50,63		1,2,3,4,6,10,16,20,25,32,40,50,63
No.of Pole	1P,2P,3P,4P	1P,2P,3P,4P		1P,2P,3P,4P
Rated Voltage(V)	230/400-240/415	230/400-240/415		230/400-240/415
Frequency(Hz)	50	50/60		50/60
Breaking Capacity(kA)	6/10kA	6		6/10kA
Rated impulse withstand Voltage(V)	4000	4000		4000
Electrical life(Circle)	1500(ln=63,80,100) &1000(ln=125)	4000		4000
Mechanical life(Circle)	8500(ln=63,80,100) &7000(ln=125)	10000		20000
Characteristic	B,C,D	B,C,D		B,C,D
Mounting	DIN rail EN60715	DIN rail EN 60715		DIN rail EN 60715
Connection	Cable/Pin-Type bus bar	Cable/Pin-Type bus bar		Cable/Pin-Type bus bar
Auxiliary Contact	Optional	Optional		Optional
Shunt Release	Optional	Optional		Optional
Under Voltage Release	Optional	Optional		Optional
Alarm Contact	Optional	Optional		Optional
Protection	Short Citcuit & Overload	Short Citcuit & Overload		Short Citcuit & Overload

Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price. If you are interested in any of our products, or wish to place a customized order, please contact us. We will do our best to meet your needs.

Yueqing Lovadon Electric Co., Ltd wsa founded in 2012, located in Liushi Chandong Industrial Zone where is near the national scenery area-Yandang Mountain. Our company covers an area of 500m² And has around 30 staff members. It has advanced automation equipment and testing equipment, with a number of high-education management team and staffs. The company speciallized in manufacturing low voltage and high voltage electrical product such as Circuit Breaker, Contactors, Distrubition Boxes, Automation products, Switches, Power source, Lightning arrester, Composite suspension insulator, and so on. Guaranteeing stable and timely supply, credible quality and sincere service, our products sell well in both domestic and overseas markets.
