| Prod Model: |
LA188-S19-H10 |
| Delivery Time: |
30 Days After Deposit |
| Color: |
White,Black,Green Yellow,Blue,Red,etc |
| Other Services: |
ODM OEM |
| Certificate: |
Ce,CCC |
| Type: |
Normal Open |
| Usage: |
Check Button |
| Kind: |
Single-pole on-off Switch |
| Brand: |
Hvacstar |
Product Description
Illuminated Latching Push Button Switch, waterproof Switch
ABOUT US:
HeCheng Electrical Co., Ltd., founded in 1995, is one of the leading manufacturers specializing in developing and producing kinds of low voltage electrical products and accessories in China. As an enterprise certified by ISO9001 system, we also get UL, IQNet, CQC, CSA etc. certifications. We have rich experience in producing and trading with advanced manufacturing equipment, power and complete testing equipments.
Technical Paramater:
| Rated insulation voltage | 250 |
| Heating current Ith | Temperature does no exceed the maximum allowed current |
| Rated voltage | 12V 24V 110V 220V |
| Rated current | AC
5-/60HZ | Resistive load | _ _ 5A 3A |
| Inductice load | _ _ 3A 2A |
| DC | Inductice load | 5A 5A 1A 0.5A |
| Inductice load | 2A 2A 0.2A 0.1A |
| Contact material | Silver Plated Gold |
| The aperture | A | B | C | D | L1 | L2 |
| 12mm | 12.4 | 17.5 | 19.8 | M12X1 | L+1.5 | |
| 16mm | 11.7 | 18.00 | 19.00 | M16X1 | L+3 | L+16.5 |
| 19mm | 14.8 | 21.8 | 29.00 | M19X1 | L+2 | L+11 |
| 22mm | 14.8 | 24.8 | 29.00 | M22X1 | L+2 | L+11 |
| 25mm | 19.6 | 27.8 | 4.5 | M25X1 | | |
| Note: L1 is the length of the terminal button; L2 is 1, 22 compound contact button length. |
Features:
1. The finger of comfort press to press position and switch to turn operation
2. The function identify
3. The auto connect ground
4. Defend the finger get an electric shock again
5. Plate chrome metals a head and install a base
6. The quakeproof bolt carry son
7. Hard,credibility,as long as 1,000,000 times machine life span
8. As long as 50,000 hours of the service life of the LED indicator
9. Touch some basecassette install
10. No need any tool
11. Fast and firm
FAQ:
Q1: Can I get a sample for testing?
A: Yes, we could offer free sample, but shipping cost should be paid at customers' side.
Q2: Can I print my logo on the products?
A: Yes, OEM and ODM are available.
Q3: How can I get the after-service?
A: If quality problem happen we promise re-send the item .
Q4: Do you have inspection procedures for products?
A: Our products100% self-inspection and testing before packing.
Q5: How about delivery time of the order?
A: 15-20 days after getting deposit.
Q6: How about payment terms?
A: 30% deposit, the rest payment balance against B/L copy.
