Immersion Gold PCB Circuit Board Taconic Tsm-Ds3 0.13mm Prototype PCB
| Price: |
US $ 1.2/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-609-V6.09 |
| Aluminum Core: |
1W / Dielectric Material |
| Minimum / Maximum Holes: |
3.5mm/6.5mm |
| Minimum Trace And Space: |
12 Mil/14 Mil |
| Final Foil External: |
1oz |
| Final Height Of PCB: |
1.2mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
White |
| Colour Of Component Legend: |
No Required |
| Via: |
No Via |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Material: |
Aluminum |
| Dielectric: |
Aluminum 5052 |
