Imporosity 99.99% Purity for The Synthesis Pbn Conating Insulation

Name: Imporosity 99.99% Purity for The Synthesis Pbn Conating Insulation
Brand: all-electronics-online.com
SKU: 807112455
Availability: InStock
Rating: 4.4 (143 reviews)

Price:	US $ 100-10000/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Application:	Insulators
Maximum Voltage:	<10KV
Type:	Insulation Crucible
Chemistry:	Ceramic
Material:	Pyrolytic Boron Nitride
Brand:	Ry

Product Description

Pyrolytic Boron Nitride of PBN LEC Crucible
Characteristic
1.Product color is between ivory white and orange-brown,nontoxic,imporosity,east processing.
2.The purity is up to 99.99%, surface densification,good has barrier properties.
3.The strength increases as temperature rises and peaked at 2200ºC, heater-resistance.
4.Acid,alkali,salt and organic reagent resistant.Meanwhile,it does not react with the
majority of molten-metal and semiconductor material.
5.Excellent thermal shock resistance,excellent thermal conductivity,low thermal expansion coefficient.
6.High resistance,high dielectric strength,low dielectric constance,low dissipation factor,
excellent microwave and infrared ray ability.
7.It has obvious anisotropy in the mechanics, heat and electricity.

Application
1.The crucible and substrate of semi-conductor single crystal and III-V compound synthesis
2.LEC crucible for the synthesis of GaAs,InP,GaP
3.MBE crucible for Molecular Beam Epitaxial.
4.VGF crucible
5.Other customizable PBN products

Product parameter

Property		Unit	Value
Lattice constant		μ m	a:2.504×10-10 c:6.692×10-10
Apparent density		g/cm3	2.0-2.19
Microhardness (Knoop) (ab plane)		N/mm2	691.88
Volume resistivity		Ω·cm	3.11×1011
Tensile strength (\|\| "C")		N/mm2	153.86
Bending strength	(\|\| "C")	N/mm2	243.63
Bending strength	(⊥"C")	N/mm2	197.76
Modulus of elasticity		N/mm2	235690
Thermal conductivity		W/m·k	"a"direction "c"direction
	(200°C)	W/m·k	60 2.60
	(900°C)	W/m·k	43.70 2.80
Dielectric strength (room temperature)		KV/mm	56

What can we do for you?

1. Sample is available.

2. Independent R&D, ISO manufacture, precise quality standards, modern logistics management, and sound marketing strategy.

3. Inquiry replied within 24 hours.

4. Patented products.

5. OEM or ODM is available.

6. Some extra accessories can be supplied.

7.The larger quantity you order,the more competitive prices you'll get.

8. Necessary Certificates can be supplied.

Why To Choose Us

1. Low MOQ:

It won't occupy too much of your money to help you to test the market you're going to enter.

2. R & D Center and Factory:

We have our own R & D center and factory, so we can supply you products at competitive price.

3. Good Service :

We treat clients as friends.

4. Good Quality :

We import top quality accessories to manufacture our products, we have confident we can offer you the best quality.

5. After-sales service:

One year's guarantee. Wearing accessories comes with the products to help you to reduce the repair bill.

Hunan Rui Yue industrial and trade Co., Ltd was established in 1997, specializing in

Research and development. Main as: Alumina/Zirconia/Aluminium nitride/Pyrolytic boron nitride and series products, Also accept OEM and ODM.

The products are widely used in lamps and lanterns, electric appliances, electric

Heating products, nozzle, auto parts, wear-resistant parts of insulation material, etc.

The company always adhere to quality survival, innovation and development, the integrity

Of the brand, to protect and thoughtful after-sales service enterprises as the goal,

Over the years, Our products are sold well all over the country, and exported to Germany,

United States, Finland, Brazil, Russia, Mexico...More than 20 countries, product quality

And service are highly praised by customers.

"Superior quality, preferential price"is our management tenet, we sincerely expect to

Cooperate with the masses of domestic and foreign customers, common development!

Welcome to visit and investigate of our company.
