Indoor High Voltage Vacuum Circuit Breaker (VS1)

Name: Indoor High Voltage Vacuum Circuit Breaker (VS1)
Brand: all-electronics-online.com
SKU: 771706145
Availability: InStock
Rating: 4.4 (36 reviews)

Price:	US $ 1200-8000/Set
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Set
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	ZN63A(VS1)-12
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	12kv
Poles:	3
Breaking Capacity:	High Voltage Circuit Breakers
Operation:	Manual Type
Speed:	High-Speed Circuit Breaker
Arc-extinguishing Medium:	Vacuum
Installation:	Fixed
Structure:	ACB
Poles Number:	3
Certification:	CCC

Product Description

ZN63A(VS1)-12
Series of Indoor High Voltage Vacuum Circuit Breaker

General Description
ZN63A(VS1)-12 series of indoor vacuum circuit breaker is used for indoor 12kv switchgear,it is suitable to control and protect transmission and distribution system such as electric network equipment and industrial&minning industry etc as their protection and control unit.
It can match with KYN28(GZS1),XGN and GG1-A series of switchgears.The products meet standards of GB1984-2003,this seriesof products include:VCB truck,isolation truck and fuse truck etc.
1.This series of VCB is used integrated design for operating mechanism and VCB body with reasonable,beautiful and compact arrangement.
2.This series of VCB adopted vertical insulation house against impact due to different weather,it can effectively prevent VIS against damage by exterior factors.
3.With two kinds of installation unit:fixed type and withdrawable type,it can meet different assembling requirements between switchgear and breaker.
Applying ambient conditions
1.Ambient temperature:-10ºC~+40ºC.
2.The height above sea level:≤1000m(besides the special requirements).
3.Relative humidity:the average humidity of a day should be no more than 95%;the average humidity of a month should be no more than 90%.
4.Saturated vapour pressure:the average pressure of a day should be no more than 2.2kPa;the average pressure of a month should be no more than 1.8kPa.
5.Earthquake intensity:not exceed 8 degrees.
6.It should be installed in the places without fire,explosion,serious filth,chemical erosion and violent vibration.

Main Technical Specification

S.N	Name		Unit	Data
1	Rated voltage		kV	12
2	Rated frequency		Hz	50
3	Rated insulation level	Rated power frequency withstand voltage	kV	42
3	Rated insulation level	Rated lighting impulse withstand voltage	kV	75
4	Rated current		A	630	1250	1600	2000	2500	3150	4000
5	Rated short circuit breaking current Rated thermal stability current (effective value)		kA	20	20
				25	25	25
					31.5	31.5	31.5	31.5
					40	40	40	40	40	40
										50
6	Rated short circuit making current Dynamic stability rated current		kA	50	50
				63	63	63
					80	80	80	80
					100	100	100	100	100	100
										125
7	Breaking operations of rated short circuit breaking current		Cycle	50,30(above 40kA)
8	Rated short-circuit duration		s	4
9	Rated operating sequence			0-0.3s-CO-180S-CO/0-180s-CO-180s-CO(above 40kA)
10	Mechanical endurance		Cycle	30000
11	Rated breaking current of single capacitor bank		A	630
12	Rated breaking current of back to back capacitor bank		A	400
13	DC component			50%

Note:1. No.11&12 are provided when needed.
2. Switchgear should with cold wind when the rated current is 4000A.

Company Introduction

General

Shaanxi Longxiang Electrical Co., Ltd. is a specialized manufacturer of making vacuum circuit breaker covering the voltage range of 12kV~40.5kV, which is located in Gaoxin 19th Road, East Development Zone, Baoji city, Shaanxi province. It occupancies total area of 18800 square meters including building area of 12800 square meters. The annual production capacity of vacuum circuit breaker is 16000 sets.

Professional management team and extensive market supply

Shaanxi Longxiang Electrical Co., Ltd is in posseeion of professional management team, main of them were from middle of high level management of large-scale enterprises in this industry, with more than 20 years working experience accumulation, professional knowledge and managerial experience, we focus on technology innovation based on market-oriented concept. The products are widely used in national power, petrochemical, smelting, aviation industry etc. And also exporting to Italy, Russia, Iran, India and other international markets. We also have established long-term strategic cooperation relations with several specialized manufactures of power transmission and distribution in the world.

Reliable technique and continuous improvement of quality control

Having professional R&D team to supply technical support, and cooperating with related research institutes, all these guarantee our product in pioneer level on its technique. Besides, our advanced production line can control the quality of any procedures, and all products will be inspected strictly before delivery.
