Industrial Mica Band Heater Element

Name: Industrial Mica Band Heater Element
Brand: all-electronics-online.com
SKU: 731035905
Availability: InStock
Rating: 4.3 (123 reviews)

Price:	US $ 3-10/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	5/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	band heater element
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Industrial Heater:	Band Heater
Sheath:	304 Stainless Steel
Insulation:	Mica Insulation
Electric Heating:	Nicr 80/20 Wire
Min Diameter:	25mm
Min Width:	25mm
Wattage:	980W
Voltage:	240V 230V 120V
Industrial Application:	Injection Molding

Product Description

Industrial mica band heater element

Introduction
Mica band heaters are efficient and economic solutions to the heating requirements of many applications., especially plastic industry. They can be found in several types of dimensions, wattage, voltages and material.
Band heaters use electric heating (NiCr 80/20 wire) to heat-up the external surface of drums or pipes and high quality mica material insulated.

Mica heaters shapes are well known in the industries. Almost any shape are possible.
The most common square, rectangular and hex-shaped mica heater can be manufactured as per customer's specifications in one or two pieces units. Available with leads or terminals.

Features:
1. Stainless Steel sheath resists rust and high temperatures, and provides firm mechanical support.
2. Mica insulation prevents heat loss, thereby lowering energy costs.
3. High temperature nickel-chromium element wire
4. Max. Watt density: 3 W/cm² (Wattage tolerance: +5% -10%)
4. Mini diameter: 25mm
5. Mini height: 25mm
Pictures for mica band heaters

BENEFITS
Energy efficient
Energy saver
Highly flexible
Durable
Maintains heat
Provide uniform heat distribution
CSA, CE and UL certified

APPLICATIONS
Injection molding
Blow-molding
Plastic extrusion
Container, pipe, or tank heating
Process applications

When ordering please specify:
1, Inside diameter and width of the heater
2, Construction type
3, Wattage and voltage
4, Type of terminal
5, Drawing where special type of holes or cutouts required

sheath	304 Stainless Steel
insulation	Mica
heating resistance wire	NiCr 80/20 wire
Max. wattage density	3 W/cm² (Wattage tolerance: +5% -10%)
Min size	25*25mm
terminations
1	Clamping mechanisms
2	Termination Styles
3	Construction Styles
