Infrared Sensor Door Release Touch Switch for Automatic Door (HF-045)

Name: Infrared Sensor Door Release Touch Switch for Automatic Door (HF-045)
Brand: all-electronics-online.com
SKU: 757684885
Availability: InStock
Rating: 4.3 (35 reviews)

Price:	US $ 20/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	HF-045
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Function:	Motion
Voltage:	12V -24V
Solution:	Sliding or Swing Door Operators
Output:	Digital Senso
Usage:	Position Sensor
Theory:	Magnetic Sensor
Type:	Infrared Sensor Switch
Principle:	Infrared
Standard:	Standard
Application:	Garage
Certification:	RoHS

Product Description

Infrared Sensor door release touch switch for automatic door (HF-045)

General specifications
Function principle Micro wave module
Detection speed min. 0.1 m/s
Marking CE
Setting angle 0 ... 40 ° in 5 ° steps
Sensing range 1500x 3500 mm (TxB) at 2200 mm mounting height and 30° tilt angle
Operating frequency 24.05 ... 24.25 GHz K-Band
Operating mode Radar motion sensor
Indicators/operating means
Function display LED red/green (see section "functional display")
Operating elements Potentiometer and programming button for setting: Method of connection, dropout time,
response time, Interference behavior
Operating elements sensitivity adjuster
Electrical specifications
Operating voltage 12 ... 36 V DC , 12 ... 28 V AC
No-load supply current I0 ≤ 50 mA at 24 V DC
Power consumption P0 ≤ 1 W
Output
Switching type active/passive
Signal output relay
Switching voltage 120 V AC / 60 V DC
Switching current max. 1 A
Standard conformity
Standards EN 60950:2000; EN 60335-1:1994; EN 301489-3 V1.4.1; EN 61000-6-1:2001, EN 61000-
6-2:2001; EN 61000-6-3:2001; EN 61000-4:2001 ; EN 300440-2 V1.1.1
Standards 2 CETECOM
Ambient conditions
Ambient temperature -20 ... 60 °C (253 ... 333 K)
Relative humidity max. 90 % non-condensing
Mechanical specifications
Mounting height max. 4000 mm
Protection degree IP54
Connection terminal strip 4-pin
Material
Housing ABS, anthracite

Established in 2008, HONGFA Automatic Door Co., Ltd is a leading manufacturer of automatic doors. We are located in Shenzhen (beside HongKong), an industrial, convenient and beautiful city in the south of China. It is very convenient to all over the world by air or sea.

HONGFA is a high-tech company that integrates development, production, sales and service. Over the years, we have designed, developed and manufactured a wide range of automatic doors, such as fast rolling curtain doors, high speed automatic doors, medical automatic sliding doors, automatic inductive doors and so on. We has passed certification of ISO9001 international quality system.

HONGFA' S full range of products are made by Germany advanced technology. As the automatic door professional manufacturer, our company has perfect quality management system and after-sale service system, has good cooperation partnership with many national key projects. Our doors have been exported to Europe, Americas, Africa, the Middle East, and other Asia countries. Germany advanced technology, top quality material, advanced management, strong development and perfect service system make us stronger and stronger.

HONGFA people have the strong responsibility on our company and clients, not only selling product and service, but also ourselves. We creat the better life style.

We are looking forwards to building a strong business partnership with you and your company.
