Inline PWM 12-24V LED Strip Dimmer Switch

Name: Inline PWM 12-24V LED Strip Dimmer Switch
Brand: all-electronics-online.com
SKU: 808173955
Availability: InStock
Rating: 4.8 (68 reviews)

Price:	US $ 1.2-1.3/Piece
Min Order:	100/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	LYD-T2
Net Weight:	36g
Gross Weight:	50g
Output:	1 Circuit
Output Current:	<6A
Static Power Consumption:	<1W
Application:	Toys
Certification:	CE
Universal:	Universal
Transmission Distance:	<50m
Material:	Plastic
Voltage:	DC5V, 12V~24voptional

Product Description

Basic Info

place of origin:	Shenzhen,China
Type:	Manual Switch
Max. Load Power:	144w
Output:	1 circuit
Output Current:	<6A
Static power consumption :	<1W
Output Power:	5V:<30W, 12V:<72W, 24V:<144W
External dimension:	663334mm

Product Description
Single color dimmer can achieve step-less dimming. It adopts the knob control manner. According to actual needs, users can transfer the light to the appropriate brightness.

Technical Parameters

Working temperature	-20-60
Supply voltage	DC5V, 12V~24V optional (specify the required voltage on orders)
0utput	1 channel
External dimension	L61×W33×H32mm
Packing size	L90xW60xH40mm
Net weight	36g
Gross weight	50g
Static power consumption	<1W
Output current	<6A
Output power	5V<30W, 12V<72W, 24V<144W

Function
Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power;

2. Adopt rotary button, its function as follows:
Rotate button to the right, brightness will be brighter, when you rotate it to the far right, the brightness is greatest.

Rotate button to the left, brightness will be darker, when you rotate it to the far left, the light will be turned off.

Our Services
1. Quality guaranteed: Special supervision team control quality.
2. After service guaranteed: Assure you the best services at all times.
3. Delivery time: Your shipment will be loaded in 10-30 days,depends on quantity.
4. Payment terms: T/T,PayPal
5. OEM & ODM are available.

Packaging&Shipping

With advantage of many years producing LED in large scale as well as advanced technicians in lamp manufacturing field. LYD entered into the lamp market which uses LED as its lamp-house, as a high-tech enterprise which specialize in producing out door&indoor decorative lighting products.

Our company's main products are: Book Lights, Flexible LED Strips, Rigid LED Strips, LED Module, LED Controller, Power Supply. Our products have been widely used in illumination, advertisement, city enlightening projects, traffic lamp, decorating, electronic gifts and toys, and many other production fields.

Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.

Through persevering efforts, we have become one of the largest suppliers in LED light field in China and also won the trust of our customers because of excellent quality and prompt delivery.

Choosing louita means choosing satisfaction and choosing benefit! We firmly believe "Technology changes the world and the world will be more brilliant because of louita
