Insulated Wire Connector

Name: Insulated Wire Connector
Brand: all-electronics-online.com
SKU: 673704022
Availability: InStock
Rating: 5 (35 reviews)

Price:	Negotiable
Trade Terms:	FOB
Min Order:	500/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Material:	Copper
Size:	Complete
Application:	Power
Type:	Insulated Wire Connector
Gender:	Insulated Wire Connector

Product Description

Insulated wire
1, Cable lugs are suitable for the connection of copper conductors in power cable with electronic equipment
2, Material: They are made of higher 99.99 % pure copper tube T2. Working temperature -55oC-150oC
3, Surface: Tin-plated

Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire
Insulation = Yes
Insulation Support = Insulation Support
Insulation Diameter (mm [in]) = 3.56 [. 140] Max.
Stud Diameter (mm [in]) = 7.92 [0.312]
Stud Size = 5/16 [M8]
Shape = RING-041
Heavy Duty = No
Material = Copper
Finish = Tin
Color = Red

ITEM NO.	Cable size		Dimension(mm)
ITEM NO.	A.W.G	mm2	Dφ	dφ	L
BN 1.25	22-16	0.5-1.5	3.3	1.7	15
BN 2	16-14	1.5-2.5	4	2.3	15
BN 3.5	12_14	2.5-4	5	3	15
BN 5.5	12_10	4_6	5.5	3.4	15
BN 8	#8	10	7.1	4.5	21
BN 14	#6	16	9	5.8	26
BN 22	#4	25	11.4	7.7	29
BN 38	#2	35	13.3	9.4	32
BN 60	1/0	50	15.4	11.4	36
BN 70	2/0	70	17.5	13.3	37
BN 80	3/0	95	19.4	14.5	38
BN 100	4/0	120	22	16.4	38
BN 150	250-300MCM	150	26.5	19.5	54
BN 180	300-350MCM	185	28.5	21	57
BN 200	400MCM	240	32.5	24	63
BN 325	500-600MCM	300	37	28	72

Shanghai Powery Industries Co., Ltd. Located in Shanghai China, our factory located in the beautiful seaside city--Qingdao, covering more than 10000sqm, with the workshop covering an area of 5000sqm, is a advanced management company, which is about 15 minutes' drive away from the Qingdao airport and about half-hour's drive away from the port.

We are engaged in the design, manufacture and marketing services of rigging, vessel and container fittings, electric power fittings, and high and low voltage transmission and distribution line fittings. We have been equipped all kinds of forging machines, casting machines, punching machines, lathes and drilling machines. "Quality and Service" is our top belief. Our products have been exported to Asia, America and Africa for many years. Most of our friends and customers are satisfied with our quality and services, on the basis of which, long-term friendships have been established.

Being ISO9001: 2008 certified and with permits for all products, we produce all products according to relative International Standards and customers' requirements.

You and your esteemed company are welcomed to visit us. Our best services, famous Qingdao beach sightseeing and delicious seafood are waiting for your presence.
