Integrated Circuit Sg3525adwr2g of Pulse Width Modulator Control IC

Name: Integrated Circuit Sg3525adwr2g of Pulse Width Modulator Control IC
Brand: all-electronics-online.com
SKU: 782045405
Availability: InStock
Rating: 4.6 (145 reviews)

Price:	US $ 0.37/Piece
Trade Terms:	FOB
Min Order:	500/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SG3525ADWR2G
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of PWM Outputs:	2
Output Current (Ma):	400(Max)
Minimum Operating Supply Voltage (V):	8
Maximum Operating Supply Voltage (V):	35
Maximum Duty Cycle (%):	49(Typ)
Rise Time (Ns):	100
Fall Time (Ns):	50
Operation Temperature Range:	0 to 70 Degree C

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

Manufacturer:ON Semiconductor
Type: power management IC
Package:SOIC-16
Max working temp.:+70ºC
Min working temp.:0ºC
Max working volt.:35V
Min working volt.:8V
Max source current:±100 mA, ±400 mA
Max reverse current:±100 mA, ±400 mA
Max switching frequency:400 kHz

Features
• 8.0 V to 35 V Operation
• 5.1 V 1.0% Trimmed Reference
• 100 Hz to 400 kHz Oscillator Range
• Separate Oscillator Sync Pin
• Adjustable Deadtime Control
• Input Undervoltage Lockout
• Latching PWM to Prevent Multiple Pulses
• Pulse−by−Pulse Shutdown
• Dual Source/Sink Outputs: 400 mA Peak
• Pb−Free Packages are Available*

Specifications
EU RoHS Compliant
Control Method Voltage Mode PWM Controller
Number of PWM Outputs 2
Output Current (mA) 400(Max)
Minimum Operating Supply Voltage (V) 8
Maximum Operating Supply Voltage (V) 35
Maximum Duty Cycle (%) 49(Typ)
Minimum Operating Temperature (°C) 0
Maximum Operating Temperature (°C) 70
Rise Time (ns) 100
Fall Time (ns) 50
Adjustable Output No
On/Off Pin Yes
Synchronous Pin Yes
Packaging Tape and Reel
Mounting Surface Mount
Package Height (mm) 2.4(Max)
Package Length (mm) 10.45(Max)
Package Width (mm) 7.6(Max)
PCB changed 16
Standard Package Name SOP
Supplier Package SOIC W
Pin Count 16
Lead Shape Gull-wing
