Intelligent Digital Dual-Display LCD Temperature Controllers

Prod Model:	WP
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Features
Various output signals
Display range: -1999~9999
Precision ± 0.2%FS, ± 0.5%FS
Decimal point can be set arbitarily
Power supply: AC100~265V, 50~60Hz, DC24V± 2V
28 kinds of input signals (thermocouple, standard signal etc. )
2 relay alarms, the state of relay's normally open/ close can be set arbitrarily,
This series controllers can be expanded to 4 relay alarms, 6 relay alarms(S80/C80).
Isolated analog quantity transmit output, output range can be set and adjusted arbitrarily
24VDC supply, just fits for matching with transmitter with 4-20mA output (2 or 3 wire). This supply connect with input circuit inside of instrument, can not be used as other power supply.

Application
This series intelligent dual-display controllers can be used to read the value of pressure or temperature in the fields:
Ocean and Oil & Gas
Food & Beverage plant
Industrial test and control
Gas tank pressure monitoring
Petroleum, Chemical industry
Hydraulic and level measurement

This is a dual display universal digital programmable temperature controller

Specifications
Model Size Panel cutout
WP-C10 48*48*108mm 44+0.5 * 44+0.5
WP-S40 48*96*112 mm (Vertical type) 44+0.5 * 92+0.7
WP-C40 96*48*112mm (Horizontal type) 92+0.7 * 44+0.5
WP-C70 72*72*112 mm 67+0.7 * 67+0.7
WP-C90 96*96*112 mm 92+0.7 * 92+0.7
WP-S80 80*160*80 mm (Vertical type) 76+0.7 * 152+0.8
WP-C80 160*80*80 (Horizontal type) 152+0.8 * 76+0.7


Ordering guide: WP-C90-PT100 input-4-20mA output
