IPS Inductive Proximity Switches

Name: IPS Inductive Proximity Switches
Brand: all-electronics-online.com
SKU: 641301425
Availability: InStock
Rating: 4.8 (141 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	IPS-A
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Position Sensor
Standard:	Standard
Application:	Warehouse
Certification:	CE
Principle:	Eddy Current
Wires:	PNP (',Three-Wires)

Product Description

Inductive sensors are used when the target is metal. These are the most widely used switches in industry today. The inductive proximity switch consists of 4 main components: coil, oscillator, detection circuit and solid state switching device. The oscillator creates a high frequency field that is emitted from the sensing face. When a metal target enters that field, eddy currents are induced in the metal target (hence the term INDUCTIVE). Energy is required from the oscillator to maintain the eddy currents in the target. INDUCTIVE PROXIMITY SWITCHES Technical Specifications of Barrel Shaped AC TYPE Model IPS-A-2 -1270 IPS-A-2.5 -1470 IPS-A-3 -1670 IPS-A-5 -1870 IPS-A-6 -2265 IPS-A-7 -2565 IPS-A-10 -3065 Size mm M12x70 M14x70 M16x70 M18x70 M22x65 M25x65 M30x65 Operating Voltage(VAC) 90-250 90-250 90-250 90-250 90-250 90-250 90-250 Max.Load Current (m A.) 200 200 200 300 300 300 300 Sen.Dis. FM (mm) NFM 2 2.5 3 5 6 7 10 4 5 6 8 9 10 15 No.Load Current (mA) 12 12 12 12 12 12 12 Voltage Drop At Full Load >15 >15 >15 >15 >15 >15 >15 Position Indication LED LED LED LED LED LED LED Cable Length (mm) 2000 2000 2000 2000 2000 2000 2000 Housing Material Brass Brass Brass Brass Brass Brass Brass

Our Corp.Specializes in studying and manufacturing magnetoelectric sensors, of the ability producing the following series with large scale.

Temperature Switches, PT100, PT1000 sensor, transmitter, and preventing cooling switches, pressure switches and sensors, liquid level switches, flow switches and turbin flow sensor, level Transmitter, position switches, proximity switches, gear tooth speed sensor, magnetic encoder, rotary sensors are marching to market.Our products can be widely applied to automobile engine, automobile-conditioner, household conditioner refrigerator, Electro-heater for appliance, solar boiler, for watching out and controlling temperature, liquid level, pressure and fluid flow parameters.

Products are matched with these famous domestic enterprises, such as Shanghai Carrier.A.O.Smith, Pentair, XinFei (Henan) Guangzhou refrigerator, Midea, , Meiling, Roshita, Hitachi of Japen etc.At the same time, we provide the OEM service.

Our products are CCC, VDE, ETL, CE, CQC, EX approved and have passed through the ISO 9001-2000 certified.

Our whole staff carries out the following operations and managing ideal:Credit, honest and meeting customer's demand.All employees are working hard on your and our business with highly attitude!
