Name: IR 12keys LED Dimmer Switch
Brand: all-electronics-online.com
SKU: 808303985
Availability: InStock
Rating: 4.6 (137 reviews)

Price:	US $ 3.3-3.4/Piece
Min Order:	5/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	LYD-T3
Output:	1 Circuit
Output Current:	<8A
Static Power Consumption:	<1W
Net Weight:	141g
Light Source:	LED
Housing Material:	Plastic
Dimmable:	with Dimmable
Appearance:	Square
Type:	Embedded
Voltage:	12V
Certification:	Ce, RoHS

Product Description

Basic Info

Place of origin:	Shenzhen,China
output:	1 circuit
output current:	<8A
Static power consumption :	<1w
Output Power:	5V:<40W, 12V:<96W, 24V:<192W
Package sizes:	10010065mm
Working temperature:	-20-60ºC
Brand name:	louita

Product Description
12-key Infrared Dimmer Is a dedicated intelligent LED lighting dimmer controls, Adopt the most advanced PWM (Pulse Width Modulation) digital dimming technology, You can manually adjust the brightness step-less. IR wireless remote control can also be used to remote dimming; Standards for commercial or home a low 86-type switch socket box installation, LED Dimmer switches can be installed to meet the light needs of commercial or home lighting in the different time and different environments, To extend the LED life span, energy saving; power and low-power LED lighting can be dimming. Is used to control a variety of led lamps as the light source, For instance, point source of light, flexible light strip, wall washer lamp, glass curtain wall light and so on; With competitive price, easy wiring, simple to use etc.; Through the infrared remote control and dimmers on the knob to adjust brightness; Gray level 255; with custom features, delay shutdown function and a fixed gray scale output.

Technical Parameters

Working temperature	-20-60ºC
Supply voltage	DC5V, 12V~24V optional (specify the required voltage on orders)
0utput	1 channel
External dimension	L87W87H53 mm
Packing size	L106xW106xH66mm
Net weight	150g
Gross weight	200g
Static power consumption	<1W
Output current	8A
Output power	5V<40W;12V < 96W;24V<192W

Details

Cautions

This products Input voltage is DC12V,other input voltage are not allowed.

Lead wire should be connected correctly,according to the wire color and the connecting diagram offers.Overload are prohibited.
