Is Series Isolation Transformer (Ultra-Isolation & Noise Suppression Transformer)

Name: Is Series Isolation Transformer (Ultra-Isolation & Noise Suppression Transformer)
Brand: all-electronics-online.com
SKU: 614889204
Availability: InStock
Rating: 4.3 (26 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	IS Series 1KVA~100KVA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Transformer
Phase:	Single

Product Description

Feature
The Ultra-Isolation & Noise Suppression Transformer are indoor air self cooling ones, which is available in the circuit of AC 50Hz and voltage less than 1000V. Input/output voltage of all transformers can be made according to order. Number of phase has three-phase and single-phase or three-phase input with single-phase/two-phase output etc. The max. Rated power will be up to 1000kVA.

Main Technical Data
Phase no.: Single-phase
Input voltage: 200V/220V/230V/250V etc
Output voltage: 220V etc
Frequency: 50Hz-60Hz
Ambient temperature: -10 º C~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min
Insulation resistance: > 2MΩ

Application
It is available in the electric supplying of electronic instruments, machinery equipment, lighting, rectifying device etc.

Remarks:
Custom-made specifications are acceptable.

Model	Rated Power	Pkg Size(cm)	Qty per pkg(Units)
IS-50VA	50VA	432035	8
IS-100VA	100VA	432035	8
IS-200VA	200VA	432035	6
IS-300VA	300VA	454020	4
IS-400VA	400VA	454020	4
IS-500VA	500VA	454020	4
IS-700VA	700VA	303035	1
IS-1000VA	1000VA	434857	1
IS-2000VA	2000VA	434857	1
IS-3000VA	3000VA	494860	1
IS-5000VA	5000VA	494860	1
IS-8000VA	8000VA	505262	1
IS-10KVA	10KVA	505262	1
IS-15KVA	15KVA	505262	1
IS-20KVA	20KVA	606270	1
IS-30KVA	30KVA	606270	1
IS-40KVA	40KVA	707280	1
IS-50KVA	50KVA	707280	1
IS-60KVA	60KVA	707280	1
IS-70KVA	70KVA	707280	1
IS-80KVA	80KVA	9095110	1
IS-90KVA	90KVA	9095110	1
IS-100KVA	100KVA	9095110	1
