LC/Upc-LC/Upc Fiber Optic Patch Cord Cable

Name: LC/Upc-LC/Upc Fiber Optic Patch Cord Cable
Brand: all-electronics-online.com
SKU: 720034805
Availability: InStock
Rating: 4.5 (77 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	LC simplex cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cable Length:	1m,2m,3m 5m, or Others
Cable Color:	12 Cable Color
Cable Diameter:	2.0mm or 3.0mm or 0.9mm, 900um
Cable Type:	High Quality Indoor Cable
Cable Jacket:	PVC, Lszh or Ofnp
Connector:	Multimode or Singlemode
Duplex:	with Duplex Clips or Use Simplex Connector
Insertion Loss:	Very Low Insertion Loss
Return Loss:	High Return Loss
Boot:	12 Colors Connector Boots
Application:	Communication
Type:	Multi-mode Fiber
Connection Structure:	LC
Certification:	ISO9001
Core:	1-144 Fiber Cores

Product Description

Fiber Optic Patch Cord, LC/UPC-LC/UPC /SM / MM 10G OM3 Duplex, with LC Fiber Optical Connector,

Fiber patch cord Complies with IEC, Telcordia GR-326-CORE standard
Low insertion loss and high return loss
PC/UPC/APC polishing
Fiber cable diameter: 0.9, 2.0, and 3.0mm
Fiber jumper of the Single or multi mode is available
Fiber optic cable implex or duplex is available
Cable jacket PVC or LSZH cable is available
Excellent changeability and repeatability
Tensile strength: 10N
Operating temperature range: -40 to 80° C
Storage temperature range: -40 to 80° C
Color of cable: Yellow (SM), Orange (MM), and Aqua (OM3)

Spec.	LC fiber optical patch cable/patch cord/ jumper
Insertion loss	Less than 0.3 dB
Return loss	UPC more than 55 dB,APC more than 60dB
Repeatability	Less than 0.2 dB
Changeability	Less than 0.1 dB
Operating temperature range	-40 to 80°C
Storage temperature range	-40 to 80°C
Tensile strength	100N
Min. bending radius	35mm
Length	Customed

Shenzhen TRT Fiber Tech. Co., Ltd is specialized in R&D, manufacturing and marketing of fiber optic such as fiber optic cable, fiber optic patch cord/jumper, fiber pigtail, fiber connector, fiber adapter, fiber attenuator, fiber patch panel, ODF, fiber splice closure and other related fiber products.

With a powerful R&D team, TRT Fiber is able to manufacture products according to customer's specifications and requests, even with customized raw materials. We not only offer OEM service, but also help many partners from all over the world to win in the market with professional technical support, excellent product solution, competitive prices, fast delivery and good service. We ensure every piece of our fiber optic products is with excellent performance and appearance.

TRT has been putting a lot of investments to keep pace with fiber optic industry standard. With high quality raw materials, advanced manufacturing equipments and highly skilled workers, we ensure every piece of our fiber optic products is with excellent performance and appearance.

Welcome to be TRT business partners, we are sure to bring you more profits. Thank you.
