Level Switches with Metal Material Bent Stem

Name: Level Switches with Metal Material Bent Stem
Brand: all-electronics-online.com
SKU: 735814045
Availability: InStock
Rating: 5 (144 reviews)

Price:	US $ 1/Piece
Trade Terms:	FOB,others
Min Order:	100/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

Product Type: LSAZ-75-1/2-300 float level switches
Product ID: P/N: LS-052
Product Description: Bent stem, made of stainless steel SUS304 or SUS316L, with G1/8" threads.
It is internal horizontal mounting level switches, applied to aerospace, air compressors, buck storage tanks, chemical dispensing systems, commercial restaurant industry, parts washers, power generation equipment, petrol and diesel pumps control and prevent
Specifications
Item
Material and parameter
Housing or stem
SUS304 or 316L
Nut
SUS304 or 316L
Float ball
Stainless steel SUS 316L
Operating pressure
180 PSI max
Temperature range
-10~120 degree C
Carry current
1.5A
Switch current
0.7Amax
Switch voltage
200Vdc or 250 Vac
Power rating
50AV
Lead wire
AWG 22, 300mm length, UL1430,
Operating level
As drawing
Set point Accuracy
± 2 mm in water
Mounting orientation
(Vertical amounting in bottom or top of v. )
As signal of flow direction Mounting orientation
Mounting thread and position
G1/8" according to client requirement on side of vessel

Our Corp.Specializes in studying and manufacturing magnetoelectric sensors, of the ability producing the following series with large scale.

Temperature Switches, PT100, PT1000 sensor, transmitter, and preventing cooling switches, pressure switches and sensors, liquid level switches, flow switches and turbin flow sensor, level Transmitter, position switches, proximity switches, gear tooth speed sensor, magnetic encoder, rotary sensors are marching to market.Our products can be widely applied to automobile engine, automobile-conditioner, household conditioner refrigerator, Electro-heater for appliance, solar boiler, for watching out and controlling temperature, liquid level, pressure and fluid flow parameters.

Products are matched with these famous domestic enterprises, such as Shanghai Carrier.A.O.Smith, Pentair, XinFei (Henan) Guangzhou refrigerator, Midea, , Meiling, Roshita, Hitachi of Japen etc.At the same time, we provide the OEM service.

Our products are CCC, VDE, ETL, CE, CQC, EX approved and have passed through the ISO 9001-2000 certified.

Our whole staff carries out the following operations and managing ideal:Credit, honest and meeting customer's demand.All employees are working hard on your and our business with highly attitude!
