Lkb-01 Water Flow Switch /Water Flow Control Liquid Flow Switch

Name: Lkb-01 Water Flow Switch /Water Flow Control Liquid Flow Switch
Brand: all-electronics-online.com
SKU: 703471112
Availability: InStock
Rating: 4.3 (81 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	LKB-01
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Pressure:	1.75MPa
Liquid Temperature:	Max100

Product Description

ENGSEN company is Professional OEM manufature!

LKB-01 Water Flow Switch/ Water Flow Control DN25
Used in Liquid Flow Lines Carrying in
Water,Air Conditioning System,Heating System,Water System

WATER FLOW CONTROL
MODEL:LKB-01

APPLICATION:

Flow control used in liquid flow lines
carrying in water of any fluid not harmful
to brass or phoshphor bronze,non flammable fluid.

SPECIFICATIONS:

Control Type: Paddle
Maximum static pressure: 10kg/cm2/20kg/cm2
Electrical switch: SPDT RATING:220VAC,15A
Connection: Screw
Case: Plastic cover with 1/2 conduit opening
Work Pressure: 1.0Mpa
Liquid Temp:max 100ºC

MOUNTING:

Flow switch may be mounted in a horizontal pipe line or vertical pipe line.
Mount the flow switch in a section of pipe
where there is a straicht run of at least 5 pipe diameter
on each side of the flow switch.
