Low Il MPO to LC 8 Fibers Single Mode Fiber Optic Patchcord

Prod Model:	TK-MPOLC8
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Patch Cord
General Names:	Fiber Patch Cord
Byname:	Fiber Patch Cables
Cable Diameter:	0.9mm,2.0mm,3.0mm
Operation Wavelenghth(Nm):	1310/1550nm
Export Markets:	Global
Cable Length:	1m.3m.5m or Customized
Operating Temperature:	-40c~+80c
Fiber Mode:	Single Mode or Multi-Mode
Application:	FTTH, FTTB, LAN, CATV
Certification:	CCC
Type:	Single Mode or Multi-Mode
Connection Structure:	Sc/LC/FC/St/Mu/MTRJ/MPO/E2000
Core:	Simplex Duplex Quard
Brand:	Takfly
Sheath Material:	PVC, Lszh

Product Description

MPO to LC Optical Cable Assembly 8 Fiber MPO/APC -8*LC/upc single mode(9/125um),Fanout 0.5meter 3.0mm


1. Details:
A patch cord is a fiber optic cable used to attach one device to another for signal routing.
MPO connector realizes high density interconnection by MT Ferrule with Fiber Ribbon.

2. Features:

Low insertion loss, high return loss
MT based Multi-fiber Connector up to 12 fibers
High credibility and stability
Good in repeatability and exchangeability

3. Application:

Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system
Telecommunication

4. Before Sale Service:

We provide professional offer. Provide detailed products test report and related specifications.
We provide professional technology support to meet the requirements of customers.
Within 12 hours of the corresponding customer inquiry, our commissioners will promptly get in touch with the customers.

5. After Sale Service:

Takfly Communications Co., Ltd. Is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments. If a material or workmanship defect arises and a valid claim is received within the warranty period, we will replace the items only and bear the shipping cost for both sides. We could not be held liable for damages to personal property due to misuse or improper care and maintenance of items. There is no fault rate for the items we delivered, if there is fiber optic equipment that does not work when you get it, just contact us. If we should be responsible for it after we test, we will replace it for you. We are equipped with the good after service department and never escape our responsibility.

6. Why contact Takfly Communications Co., Ltd?

The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry.

1. Fast delivery
2. Competitive price
3. Professional product and technical support
4. Prompt answer for any question or inquiry
5. Reliable quality, OEM service available
6. Longtime warranty
7. Value-added service: Except good products, we can provide good services on logistic and other help you may need.

For any question, pls feel free to contact us. Your inquiry is expected! Warmly welcom you to inquiry us for this product


MTP&MPO TEST VAULE DATA R
MM PC	850nm		1300nm
	IL	RL	IL	RL
Standard insertion loss	0.2--0.5	32--35	0.1--0.3	35--37
Low insertion loss	<=0.35	32--35	<=0.2	35--37
SM PC	1310nm		1550nm
	IL	RL	IL	RL
Standard insertion loss	0.2--0.7	51--54	0.1--0.35	55--57
Low insertion loss	<=0.35	51--54	<=0.2	55--57
SM APC	1310nm		1550nm
	IL	RL	IL	RL
Standard insertion loss	0.2--0.7	61--64	0.1--0.35	65--67
Low insertion loss	<=0.35	61--64	<=0.2	65--67
LC	850nm		1300nm
	IL	RL	IL	RL
	<=0.2	50-54.9	<=0.15	50-54.9
