M12 Female Connector 12pin 90 Degree Cable Connector for Sensor and Actuator
| Price: |
Negotiable/Piece |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,Western Union,Money Gram |
| Prod Model: |
MC12C2RSG3AB14 |
| Standard: |
IEC 61076-2-101 |
| Key Coding: |
a-Coding |
| Number Of Pins: |
12 Pin |
| Connection Type: |
Single Ended Cable |
Product Description
M12 male connector 12pin 90 degree cable connector for sensor and actuator1. DescriptionsM12 Pre-molded (PUR/PVC)cable connectors with 12mm thread locking mechanism, rated IP67 protection degree, contacts configuration covers pins of 3-, 4-, 5-, 8-, 12 poles, 360°EMC shielding is available for option. Compliant with IEC 61076-2-101 and mainly designed for signal transmission. (1) PUR and PVC cable for option
(2) Cable length: 1M, 2M, 3M or base on customer requirement
(3) Degree of protection IP 67
(4) 2, 3, 4, 5, 8, 12 poles per connector are available
(5) Anti-vibration locking screw design2. Material dataContacts plating: Gold plated, thickness 3μ"
Cable jacket material: By Custom
Overmold/ Shell: TPU
Connector contacts: Brass with gold plated
Coupling nut/screw: Brass with nickel plated screw| Standard | IEC61076-2-101 | Gender | Female |
| Orientation | Right angled | Coding | A-code |
| Sealing | O-ring | IP rating | IP67 |
| Wire termination | Soldering | Rated current | 1.5 A |
| Shielding | Non-shielded | Rated voltage | 30 V |
| | | |
3. ApplicationsStandard sensor, actuator, encoder, servo motors
Factory automation and process control
Packaging, labeling and logistic devices
Industrial instrumentation
Commercial electronics PCBA
Industrial safety light curtain, light grid, switches
Power supplyIndustrial safety light curtain, light grid, switches
(1) Screws/ nuts material: Brass C3604 with 120μ" nickel plated, CNC parts.
(2) Male contacts material: Brass C3604, 3μ" gold plated on nickel base, machined solid pin.
(3) Female contacts material: Phosphor bronze C5441 with 3μ" gold plated on nickel base, machined solid pin.
(4) Temperature Range: Dynamic -25 ~ 80ºC, Static: -40 ~ 80ºC/ 90ºC.
(5) Protection degree: IP67 in locked status, IP68 base on customer specific requirements.
(6) Cable bending endurance: ≥3000 times, bending angle ±90°, loading 250g, frequency 40 times per minute, axle radius 12.7mm.
(7) RoHS compliant.
6.Product centificate
7. Product packaging(1) Our standard packing: Individual part with transparent PE bag with label;
(2) Carton size: 44.5*36.5*23.5(mm)
(3) OEM package available(4) Delivery: 1~ 3 weeks
7.FAQ(1) Q:Are you a manufacturer or trading company?
A:We are a connector factory.
(2) Q: What is the necessary information needed for quotation?
A:The series(M5,M8,M12,7/8"), coding, male or female, pin number, cable length etc.
(3) Q:What does Cableforce can provide for the product' certification?
A: IP67, CE and RoHS.
(4) Q:Can you provide samples?
A:Of course can be provided.
(5) Q:Sample lead time?
A:2-4 workdays
(6) Q: Volume order lead time?
A:3-10 workdays
(7) Q: How do you ship the finished product?
A:we can contact the shipping company or your shipping agent.The formal shipping way:DHL,FEDEX,UPS,TNT
