Magnetic Liquid Flowmeter with Switch (Relay-Output) for Kerosene, Oil, Water
| Price: |
US $ 400-3000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
2/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
TFL Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Measuring Range: |
15 to 100% |
| Max. Flow Rate: |
1.5 to 10m3/H (Water) |
| Min. Flow Rate: |
185 to 1300m3/H (Water) |
| Output: |
4 to 20mA |
| Max. Pressure: |
Dn50 to Dn80tpn40 |
| Media Temperature: |
-40 Degrees Celsius to +120 Degrees Celsius |
| Ambient Tempt.: |
- 25 Degrees Celsius to +65 Degrees Celsius |
| Humidity: |
Above 85% |
| Storage Tempt.: |
- 20 Degrees Celsius to + 60 Degrees Celsius |
| Class Of Protection: |
IP65 |
Product Description
Inductive Magnetic Flow Meter | Tosilon AutomationDesign and Manufacturing according to CE Standard
Magnetic Liquid Flowmeter with Switch (Relay-Output) for Kerosene, Oil, Water (Ex Approved)IntroductionTFL55 Magnetic Flow Meter Series are fit for the measurement of liquid in pipes. The advantage is it can be installed from any direction, neglecting the influence of liquid. TF55 Series can display current flow rate of volume and mass.
With its special design,TFL55 Series is suitable for the measurement of liquid medium which flowing stably without caking and sedimentation.
TFL55 Magnetic Flow Meter Series is your best choice of process controlling instrument under bad condition.Feature· Special Design in Structure, much durable in application
· Magnetic Coupling System in measurement
· Multi to installation Type: vertical and horizontal
· Wide range of application
· Wide Measuring Range
· Easy Display
· Available for Flow Control, Monitoring, 4 to 20mA, 2 to wiredMeasureing PrincipleThe rotational direction of the paddle alters along the axis when the paddle is pushed by the flowing media until the pushing force equal to the reacting force of the paddle plus the tension force of the spring. The angular position of the paddle or balance position of the paddle indicates the flow of the media.
Processed by the Permanent magnetic inductor, the movement of the pointer is driven by the Magnetic Coupling Servo System. Meanwhile, the flow value is display on the dial and is transmitted to the electrical converter.
This measuring principle is of high reliability and safety. The value shown is valid for the calibrated media or media with similar physical properties.
Outline Structure
General Technical Data (For details, please contact Tosilon)Measuring Range
15 to 100%
Max. Flow Rate
1.5 to 10m3/h (water)
Min. Flow Rate
185 to 1300m3/h (water)
Output
4~20mA
Max. Pressure
DN50 to DN80 PN40
DN100 to DN200 PN1.6
DN250 to DN400 PN1.0
Accuracy
2.5% F.S
Media Temperature
-40 oC to +120 oC
Ambient Tempt.
-25 oC to +65 oC
Humidity
≤ 85%
Storage Temp.
-20 oC to + 60 oC
Class of Protection
IP65For more information, please contact Tosilon
Your Global Partner for Automation
www.tosilon.com
| DN | Code of Flowrate | Measuring Range
(water, m 3 /h) | Pressure Drop
(kPa) |
| 50 | F55.1 | 1.5 to 10 | 120 |
| F55.2 | 3.0 to 30 | 50 |
| 65 | F56.1 | 1.5 to 15 | 40 |
| F56.2 | 4.0 to 30 | 60 |
| 80 | F58.1 | 4.0 to 24 | 40 |
| F58.2 | 10 to 60 | 60 |
| 100 | F510.1 | 6.0 to 40 | 40 |
| F510.2 | 8.0 to 80 | 60 |
| 125 | F512.1 | 10 to 60 | 40 |
| F512.2 | 20 to 120 | 60 |
| 150 | F515.1 | 15 to 100 | 35 |
| F515.2 | 30 to 200 | 55 |
