Matt Blue Solder Mask PCB Board Quick Turn Around Prototype
| Price: |
US $ 1.01/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-652-V6.52 |
| Final Foil External: |
1.5 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Green |
| Colour Of Component Legend: |
White |
| Minimum Trace And Space: |
6.5 Mil/8 Mil |
| Minimum / Maximum Holes: |
0.4/4.5mm |
| Via: |
Plated Through Hole(Pth) |
| Board Plating: |
0.0030" |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company ProfileBicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Technology Information
Design For Manufacture| Serial NO. | Procedure | Item | Manufacturing capability |
Large
volume
(S<100 m²) | Middle
volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 84 | Special tolerance | Board thickness
of flying probe
test | 0.6-4.0mm |
| 85 | Panel size
of flying
probe test | Size≤900
X600mm,
Small size
can be
compensated
through
manufacturing
procedure |
| 86 | Panel size
of fixture test
method | Size≤460
X380mm,
Small size
can be
compensated
through
manufacturing
procedure |
| 87 | Board thickness
of fixture test
method | 0.4-6.0mm |
| 88 | Tolerance of
press-fit hole | ±2mil |
| 89 | Tolerance
of NPTH | ±2mil |
| 90 | Tolerance of
PCB thickness | 1.0mm≥PCB
thickness,
Tolerance ±
0.1mm;1.0mm
≤PCB thickness,
Tolerance ±10% |
| 91 | Tolerance of
depth of
countersunk
hole | ±0.2mm |
| 92 | Depth tolerance
of blind slot | ±0.2mm |
| 93 | Maximum
shipment
size | Size≤1200
X600mm
(Double side,
no test required) |
| 94 | Size≤1000
X600mm
( Multilayer,
no test required) |
| 95 | Minimum
shipment
size | 10X10mm |
| 96 | PCB thickness
of HASL | 0.8-3.0mm
(Hole less
0.5mm should
be use via-plug
or mask-tent ) |
| 97 | HASL PCB
Size | Size≤600
X460mm |
| 98 | PCB thickness | 0.15-7.0mm |
| 99 | Depth of V
groove | 0.8-3.2mm |
| 100 | Distance of
non-continuous
v-groove | ≥7mm |
| 101 | Max. drill
diameter | Size≤6.5mm
(Counterbore
or router will
be used for
holes more
than 6.5mm,
Min.tolerance
±0.1mm ) |
| 102 | Max. countersink
diameter | Size≤6.5mm
Countersink
can be used
counterbore
drill or router) |
| 103 | Distance of
Bevel | Size≥11mm | Size≥5mm | Size≥5mm |
| 104 | Thickness of
peelable mask | 0.2-1.5mm ±0.15mm |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
